System design
Doc. # 177/52705
Rev. 1.0
71
Pump configuration
The controller can use a mixture of switch and analogue voltages as the pump input. In addition, the
power steer function can be used as an extra input to the pump if the pump motor is required to supply
pump and power steering.
NOTE: Pump motors always run in speed mode. Ensure the motor slave is also configured for speed mode in
6060h.
General Setup
Configure the pump features at 2A00
h
:
Inhibit pump when BDI drops below cut-out level. If already operating when the cut-out occurs, the
pump will continue to operate until all pump inputs are inactive.
Drive Enable switch and/or Seat switch input disables pump.
Ignore Line Contactor state. Allows the pump to operate if it is not connected to the battery
through the line contactor. Should be set if the pump also supplies power steering and the power
steer is required to operate when the line contactor is open.
Use Power Steer target velocity as pump input, if pump also supplies power steering.
Enable minimum pump speed. Enable this to force the pump to run at minimum speed (2A01
h
, 2)
even when there is no trigger. Can be used to maintain minimum pump pressure.
Pump to stop on Low Battery. Enable to force pump to stop immediately on low battery condition.
Use power steer demand to minimum pump speed. Enable this to force the pump to use power steer
demand as a minimum speed. Can be used to maintain minimum pump pressure for power steering.
Set the pump minimum and maximum speed, maximum torque, acceleration and deceleration at
2A01
h
. The pump speed is calculated as the value from the inputs multiplied by the maximum speed.
Priority/additive inputs
Each pump input can be configured as a priority input or an additive input. When calculating the pump
demand, the controller selects the demand from the highest priority active input, and then adds the
demand from all the active additive inputs.
Configure priority/additive levels in 2A10
h
and 2A11
h
, and 2A20
h
to 2A26
h
.
Pump throttles
There are 2 pump throttle inputs, which can be configured independently at 2A10
h
and 2A11
h
. The
pump throttles allow proportional control of the pump speed.
Configure inputs as priority or additive and set the voltage levels in the same way as the traction
throttle. The pump throttles must be mapped to analogue inputs.
Pump switches
There are 7 pump switch inputs. Configure each input as priority or additive and assign it a value at
2A20
h
to 2A26
h
. The pump switches must be mapped to digital inputs.
Pump Driveability Profiles
Pumps have configurable driveability profiles. Profiles are triggered by pump driveability select switches
(2152
h
and 2153
h
). One or more of these switches must be mapped to enable pump profiles.
