Sfere DGN175 U - Programming of the Advanced Functions

To the menu ANA
Function extraction of the square root
(mV, V or mA inputs).
√ of the measure brought back in % of the
programmed measure range.
Eg.: Input 4-20 mA  12 mA gives 0.707 (√0.5).
Special linearisation:
Recording of an unlinear curve
programmable in X and in Y.
Maximum: 20 points.
Number of points:
from 3 to 20
Programming of the abscises
in electrical values of the input.
Programming of the ordinates
in display value.
0.5%
1%
2%
5%
10%
25%
50%
100%
* If input other than Temperature
Coeff. Sec.
0 0.15
1 0.4
2 0.7
3 1
4 1.8
5 2.5
6 3
7 3.5
8 4
9 5
10 6
4.4.3 Programming of the advanced functions
CF.AdV
Typical response time
according to the coefficient
(for a variation from 10 to
90% of the input signal):
CF.AdV
Percentage of the measure
variation on which the filter
will be active:
FunCt
LInEA
A
rOOt
LiSPE
nb.PtS
0003
000.00
AbSC.
OrdI.
A00
00.00
A01
Y00
Y01
00.00
CUt
nO
Yes
fiLt
COEFF.
0
rAnGE
100
Linear
Programming of
the Cut-off
Value in display
points.
Programming of the
digital filtering in case
of unsteady input.
Coefficient:
from 0 to 10.
If = 0
If ≠ 0
Cut: Value below which
the display will be held at
the down scale
*
*
p12
