Transmission rank of the bytes inside an integer:
H-L: MSB transmitted first
L-H: LSB transmitted first
Time delay before any response:
OFF: Typical delay 10 ms
On: Typical delay 75 ms
See the menus tOr
or SECU
nO: No action.
FCt.P: Function moving of the decimal point (enter the position).
CLrM: Function 0 reset of the min. and max.
HOLd: Function display hold.
tArE: Function tare (process, resistance and potentiometer inputs).
See the features of the digital data link p26
Choice of the action in case of activation of the logic input 1:
Choice of the action in case of activation of the logic input 2:
* Function HOLd: In case of activation of the logic input
the display and the analogue output will remain fixed
even if the input signal varies.
The relays will carry on reacting to the input signal.
4.4.6 Programming of the RS485 output (option)
Communication parameters
Must be between 1 and 255.
4.4.7 Programming of the logic inputs (option TOR)
