Status of the relay 2 in case of sensor break:
Disconnecting of the
sensor break
detection.
Inactive relay active relay de-activated
Status of the relay 2 in case of error:
Inactive relais active relay de-activated
See the self-diagnosis error codes p25
Detection of the sensor break on the inputs: mV,
temperature, resistance (<400Ω) or mA (if the down
and up scale < 3.5 mA)
* Idem for the relays 3 and 4 (if option 4 relays)
If mV or temperature input
Status of the relay 1 in case of sensor break:
Inactive relay active relay de-activated
Inactive relay active relay de-activated
Programming of a fallback value:
00.00 < x < 22.00 (mA)
00.00 < x < 11.00 (V)
Status of the analogue output in case of sensor break.
Programming of a fallback
value:
00.00 < x < 22.00 (mA)
00.,00 < x < 11.00 (V)
dEtEC.: In mV or temperature input, the sensor break detection
can be disabled in order not to disturb some calibrators swhich
may be sensitive to the sensor break detection current.
Self-diagnosis: The digital panel meter permanently watches its
components for any drifts. The self-diagnosis serves to warn the
user in case of abnormal increase of these drifts before they may
provoque false measures.
Status of the relay 1 in case of error:
Status of the analogue output in case of self-
diagnosis error.
Menu can vary depending on the input type and the output options
4.4.8 Safeties Menu programming of the safety functions: Sensor break / self-diagnosis
