Sfere DGN175 U - 8 Annexe: Modbus

BYTE
BYTE
Table of the units
Measures
The following parameters: sensor primary measure, final measure, min. and max.
of the final measure and the values of the analogue outputs are transmitted in the
form of a module and a unit associated with a position of the decimal point.
Eg.:
Word address
Decimal value
Coding
0
10 094
module
1
12 289
point / unit
Coding of the integer decimal point / unit
H L
Dec.point unit: code of correspondance in the list hereunder
Value of the quartet: quartet haut de l’octet H
0: no decimal
16: 1 decimal
32: 2 decimals
48: 3 decimals nombre de décimales
Eg.: 12 289 = 48 X 256 + 1
The integer encodes the unit V with 3 decimals
Hence the measure read is 10.094 V
Word address
Description
0
Sensor primary measure.
1
Decimal point/unit.
2
Final measure.
3
Decimal point/unit
4
Final measure min.
5
Decimal point/unit
6
Final measure max.
7
Decimal point/unit
8
Value of the analogue output.
9
Decimal point/unit
12
Auto diag 1
13
Auto diag 2
14
Status of the relay 1.
15
Status of the relay 2.
16
Status of the relay 3.
17
Status of the relay 4.
Integer autodiag n°2: (address 13)
Bit 0
Bit 15
Integer autodiag n°1: (address 12)
(9)
(8)
(6)
(5)
(2)
(1)
(0)
bit
8 . ANNEXE: MODBUS
8.1 Table of the Modbus addresses
p26
Code
Unit
000
001
V
002
KV
003
A
004
KA
005
W
006
KW
007
MW
008
GW
009
VAr
010
KVAR
011
MVAR
012
GVAR
013
VA
014
KVA
015
MVA
016
GVA
017
Wh
018
KWh
019
MWh
020
GWh
021
VARh
022
KVARh
Code
Unit
023
MVARh
024
GVARh
025
Hz
026
Khz
027
Deg
028
Ohms
029
Kohms
030
h
031
mn
032
s
033
%
034
cos PHI
035
to 099 free
Code
Unit
100
°C
101
°F
102
%
103
mm
104
cm
105
m
106
km
107
mBar
108
Bar
109
Pa
110
Kpa
111
Kg/cm2
112
PSI
113
mCE
114
l/s
115
l/mn
116
l/h
117
m3/s
118
m3/mn
119
m3/h
120
tr/s
121
rad/s
Code
Unit
122
mm/s
123
cm/s
124
m/s
125
m/mn
126
m/h
127
mm3
128
cm3
129
m3
130
g
131
kg
132
t
133
l
134
hl
135
Rpm
136
CP/mn
137
PH
138
mV AC
139
V AC
140
KV AC
141
mA AC
142
A AC
143
KA AC
Code
Unit
144
mV DC
145
V DC
146
KV DC
147
mA DC
148
A DC
149
KA DC
150
Ohms
151
Kohms
152
Mohms
153
US.gal/s
154
US.gal/min
155
US.gal/h
156
US.gal
157
lb
158
C
159
imp
160
CP
161
mA
162
A
163
mA.h
164
A.h
165
µV
166
mV
(0) Programming error
(1) Offset error
(2) Calibration error
(5) CJC error
(6) Measure overrange of 10% of the caliber
(8) Sensor break
(9) Measure overload
(eg.: measure of 15 V on caliber 10 V)
Integer status relays 1 to 4: (address 14 to 17)
Bit 3
Bit 0
Bit 15
Measure overrange of 10% of the caliber.
1 : Led on
1 : Led blinking: mode recording ON and
measure not in alarm
1 : Relay ON
1 : Alarm recorded
Unité (octet L)
0 : aucune
1 : V
2 : kV
etc ...
