Remove all pieces of tape shown in the illustration below. Then
open the original cover/SPF and remove protective materials.
After that, take out the bag containing the power cord and TD
cartridge.
3
Release the scan head locking switch.
The scan head locking switch is under the original table.
AL-1216 AL-1225
Lock Unlock
Grasp here and turn in
the direction of the arrow.
To Next Page
