14
Follow the steps below to load paper into the tray.
PAPER
For best results, use only paper recommended by SHARP.
* Do not use non-standard envelopes, and envelopes that have metal clasps, plastic
snappers, string closures, windows, linings, self-adhesive, patches or synthetic
materials. Do not use envelopes that are filled with air or envelopes that have
labels or stamps attached. These will cause physical damage to the unit.
** For paper weighing from 104g/m
2
to 128g/m
2
(28 lbs. to 34.5 lbs.), A4 (8-1/2" x
11") is the maximum size that can be fed through the single bypass or the multi-
bypass tray.
• Special papers such as transparency film and labels envelope must be fed one
sheet at a time through the single bypass or the multi-bypass tray.
Type of paper
feeding
Type of media Size Weight
Paper tray Standard paper A4 (210mm x 297mm)
A5 (148mm x 210mm)
B5 (182mm x 257mm)
Letter (8-1/2" x 11")
Legal (8-1/2" x 14")
Invoice (5-1/2" x 8-1/2")
56g/m
2
to
80g/m
2
(15 lbs. to
21 lbs.)
Single bypass/
Multi-bypass
tray
Standard paper and
thick paper
A4 (210mm x 297mm)**
A5 (148mm x 210mm)
A6 (105mm x 148mm)
B5 (182mm x 257mm)
B6 (128mm x 182mm)
Letter (8-1/2" x 11")**
Legal (8-1/2" x 14")
Invoice (5-1/2" x 8-1/2")
52g/m
2
to
128g/m
2
(14 lbs. to
34.5 lbs.)
Special
media
Transparency
film
A4 (210mm x 297mm)
Letter (8-1/2" x 11")
Envelope* International DL
(110mm x 220mm)
International C5
(162mm x 229mm)
Commercial 10
(4-1/8" X 9-1/2")
Monarch
(3-7/8" X 7-1/2")
3
LOADING PAPER
