17
3
BYPASS FEED (including special paper)
The multi-bypass tray (AL-1225) or the single bypass (AL-1216) can be used to feed
standard paper, transparency film, labels, envelopes, and other special purpose
paper. Paper measuring from A5 to A4 (148mm x 210mm to 210mm x 297 mm) (5-1/
2" x 8-1/2" to 8-1/2" x 14") and in the weight range of 52g/m
2
to 128g/m
2
(14 lbs. to
34.5 lbs.) can be used in this tray. (For paper weighing from 104g/m
2
to 128g/m
2
(28
lbs. to 34.5 lbs.), A4 (8-1/2" X 11") is the maximum size.)
The multi-bypass tray (AL-1225)
1
Open the multi-bypass tray and extend the tray.
2
Set the paper guides to the paper width. Insert the paper (print
face down) all the way into the multi-bypass tray.
• The multi-bypass tray (AL-1225) can hold maximum of 50 sheets of
paper. (Capacity will vary depending on the type of paper loaded.)
The single bypass (AL-1216) can hold one sheet of paper.
• The original image must be smaller than the paper or media for
copying. If the original image is bigger than the paper or media, this
may cause smudges on the edges of the copies.
To close the multi-
bypass tray,
perform step 1
and then step 2 in
the illustration and
push the round
projections at the
right of the tray
until they click.
Print face
