Composite video Connection
If your external device has composite video jacks/sockets, connect them to the television using a composite
video cable and an audio Phono cable.
AV Source
External Device (Output)
Composite video/audio cable (not supplied)
Video CVBS
Getting Started
Video CVBS
If your external device has component video jacks/sockets, connect them to the television using a component
video cable and an audio Phono cable.
AV Source
Component video Connection
A
Pb (blue)
Video / Y (green)
Pr (red)
Pb (blue)
Video / Y (green)
Pr (red)
L (White)
R (red)
L (White)
R (red)
External Device (Output)
Component video cable (not supplied)
L+R Phono Audio cable (not supplied)
L (White)
R (red)
L (White)
R (red)
