APPENDIX
for US
EL-9650 functions
Major- Sub- Minor- Name Description Example of use
category category category
DRAW G 2 INITIAL Return graph screen to its INITIAL
SHADE default setting (clear shade)
ZOOM A ZOOM 1 Auto Automatic scale setting Auto
(relationship of Ymin and
Ymax is adjusted to the
relationship of Xmin and
Xmax)
2 Box Draws a box then defines Box
display screen
3 In Enlarges graph display with In
the cursor as the center
4 Out Reduces graph display with Out
the cursor as the center
5 Default Draws graph by setting to Default
the standard screen variable
(default setting values)
6 Square Draws graph by making Square
the pixel size of X and
Y axis equal
7 Dec Draws graph by setting ∆X Dec
and ∆Y to 0.1
8 Int Draws graph by setting ∆X Int
and ∆Y to 1
9 Stat Draws graph by displaying Stat
all points of statistical data
B Set magnification of X and Y Press
®
to
FACTOR axis by manual entry open magnification
input screen
