Sharp GF-800Z User Manual

7
RADIO OPERATION
Refer to the instructions on page 8.
Press the RADIO button of the FUNCTION selector.
Slide the BAND selector to the FM, AM, SW1 or SW2 posi-
tion.
Rotate the TUNING control until the desired broadcast is
received. The FINE TUNING control functions only for
SW1 and SW2 bands.
With the BAND selector in the FM position, set the FM
MODE switch to the STEREO position.
Even with the FM MODE switch in STEREO position, mono
broadcasts can be. received if the station is not transmitting
a stereo programme at that time. If stereo reception is
unsatisfactory, set the FM MODE switch to the MONO
position.
• Adjust volume and sound quality (refer to instructions on page
9).
• ADJUSTING THE ANTENNA Adjust the aerial appropriately to obtain the best reception on the band selected.
FM BROADCASTS
Raise and extend the telescopic rod
aerial. Adjust the position and length of
the antenna until FM boradcast recep-
tion signal is at peak strength.
AM OR SW1 BROADCASTS
Turn or locate the unit to receive peak
signal strength of the AM or SW1
broadcast.
SW1 OR SW2 BROADCASTS
Raise and extend the telescopic rod
aerial vertically to its full length.
10

Sharp GF-800Z Specifications

Power

AC power source voltage	110V - 127V and 220 - 240V
DC power source voltage	15V
Frequency	50/60Hz

Output Power

PMPO output power	52W (26W + 26W)
MPO output power	40W (20W + 20W)
RMS output power	26W (13W + 13W)

Tape Recorder Specifications

frequency response for normal tape	30Hz — 14, 000Hz
frequency response for CrO2 tape	30Hz - 16, 000Hz
frequency response for metal tape	30Hz - 17, 000Hz
signal/noise ratio for Deck 1 playback	55 dB
signal/noise ratio for Deck 2 recording	50 dB

Impedance

external mic input impedance	600 ohms
phono/line in input impedance	50 kohms/50 kohms
loaded impedance for headphones	8 ohms — 32 ohms
loaded impedance for external speakers	8 ohms — 16 ohms
line out impedance	0.6V/50 kohms

Radio Specifications

AM frequency range	526.5 kHz - 1606.5 kHz
SW1 frequency range	2.3 MHz - 7.3 MHz
SW2 frequency range	7.3 MHz - 22 MHz
FM frequency range	87.6 MHz - 108 MHz

Speaker Specifications

woofer size	16 cm (6-1/2")
tweeter count	2
speaker impedance	8 ohms
maximum input	26W

Weight and Dimensions

width	681 mm (26-13/16")
height	225 mm (8-7/8")
depth	210 mm (8-1/4")
weight	8.8 kg (19.4 lbs.) without batteries
