Sharp LC-40LE530E Service Manual

97
LC-32LE530
LC-40LE530
REF No. PARTS DESCRIPTION *
PRICE
CODE
R658 30022080 RES SMD 1/16W 300R J 0402 RoHS G --
R659 30049522 RES NET 1/16W 10K J 8P 0402 ROHS G --
R66 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R660 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R664 30000735 RES SMD 1/10W 4.7R J 0805 ROHS G --
R667 30021984 RES SMD 1/16W 1.6K J (0402) RoHS G --
R669 30021994 RES SMD 1/16W 10K F 0402 ROHS G --
R67 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R670 30021994 RES SMD 1/16W 10K F 0402 ROHS G --
R673 30021994 RES SMD 1/16W 10K F 0402 ROHS G --
R675 30022063 RES SMD 1/16W 560R J 0402 ROHS G --
R677 30022063 RES SMD 1/16W 560R J 0402 ROHS G --
R679 30063139 RES SMD 1/16W 715R F 0402 ROHS G --
R68 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R689 30021960 RES SMD 1/16W 47R J 0402 ROHS G --
R69 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R690 30021960 RES SMD 1/16W 47R J 0402 ROHS G --
R691 30022046 RES SMD 1/16W 2.2K J 0402 RoHS G --
R693 30022046 RES SMD 1/16W 2.2K J 0402 RoHS G --
R695 30022084 RES SMD 1/16W 33K J 0402 RoHS G --
R696 30022084 RES SMD 1/16W 33K J 0402 RoHS G --
R698 30022073 RES SMD 1/16W 2K J 0402 ROHS G --
R699 30022042 RES SMD 1/16W 1K J 0402 RoHS G --
R7 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R70 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R700 30022042 RES SMD 1/16W 1K J 0402 RoHS G --
R701 30022042 RES SMD 1/16W 1K J 0402 RoHS G --
R705 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R706 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R707 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R708 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R709 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R71 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R710 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R711 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R712 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R715 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R716 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R717 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R718 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R719 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R72 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R720 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R721 30022065 RES SMD 1/16W 56R J 0402 ROHS G --
R724 30038984 RES NET 1/32W 100R J 8P 0402 ROHS G --
R725 30038984 RES NET 1/32W 100R J 8P 0402 ROHS G --
R727 30038984 RES NET 1/32W 100R J 8P 0402 ROHS G --
R735 30022057 RES SMD 1/16W 22K J 0402 RoHS G --
R736 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R737 30022058 RES SMD 1/16W 22R J 0402 ROHS G --
R739 30022055 RES SMD 1/16W 220K J 0402 ROHS G --
R74 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R740 30022055 RES SMD 1/16W 220K J 0402 ROHS G --
R742 30022073 RES SMD 1/16W 2K J 0402 ROHS G --
R743 30022073 RES SMD 1/16W 2K J 0402 ROHS G --
R745 30022068 RES SMD 1/16W 6.8K F 0402 ROHS G --
REF No. PARTS DESCRIPTION *
PRICE
CODE
R746 30022051 RES SMD 1/16W 2.7K J 0402 ROHS G --
R747 30022088 RES SMD 1/16W 680R F 0402 ROHS G --
R748 30010641 RES SMD 1/10W 27R J 0805 ROHS G --
R749 30006462 RES SMD 1/10W 22R J 0805 ROHS G --
R751 30022055 RES SMD 1/16W 220K J 0402 ROHS G --
R752 30022055 RES SMD 1/16W 220K J 0402 ROHS G --
R758 30022069 RES SMD 1/16W 6.8K J 0402 RoHS G --
R759 30021960 RES SMD 1/16W 47R J 0402 ROHS G --
R76 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R760 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R761 30022118 RES SMD 1/16W 75R J 0402 RoHS G --
R762 30022118 RES SMD 1/16W 75R J 0402 RoHS G --
R763 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R764 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R765 30042505 RES NET 1/32W 33R J 8P 0402 ROHS G --
R769 30022065 RES SMD 1/16W 56R J 0402 ROHS G --
R77 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R770 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R773 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R775 30022065 RES SMD 1/16W 56R J 0402 ROHS G --
R776 30022065 RES SMD 1/16W 56R J 0402 ROHS G --
R777 30022065 RES SMD 1/16W 56R J 0402 ROHS G --
R778 30045875 RES NET 1/16W 56R J 8P 0402 ROHS G --
R779 30045875 RES NET 1/16W 56R J 8P 0402 ROHS G --
R78 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R780 30045875 RES NET 1/16W 56R J 8P 0402 ROHS G --
R781 30045875 RES NET 1/16W 56R J 8P 0402 ROHS G --
R782 30045875 RES NET 1/16W 56R J 8P 0402 ROHS G --
R783 30045875 RES NET 1/16W 56R J 8P 0402 ROHS G --
R784 30045875 RES NET 1/16W 56R J 8P 0402 ROHS G --
R785 30045875 RES NET 1/16W 56R J 8P 0402 ROHS G --
R786 30022041 RES SMD 1/16W 1K F 0402 ROHS G --
R787 30022041 RES SMD 1/16W 1K F 0402 ROHS G --
R788 30022000 RES SMD 1/16W 470K J 0402 RoHS G --
R789 30022000 RES SMD 1/16W 470K J 0402 RoHS G --
R790 30022121 RES SMD 1/16W 820R J 0402 ROHS G --
R791 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R793 30021960 RES SMD 1/16W 47R J 0402 ROHS G --
R794 30045875 RES NET 1/16W 56R J 8P 0402 ROHS G --
R795 30022043 RES SMD 1/16W 1M J 0402 ROHS G --
R8 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R803 30022132 RES SMD 1/16W 0R 0402 ROHS G --
R804 30022132 RES SMD 1/16W 0R 0402 ROHS G --
R815 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R82 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R825 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R826 30022085 RES SMD 1/16W 33R J 0402 RoHS G --
R829 30021958 RES SMD 1/16W 47K J 0402 RoHS G --
R83 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R830 30022057 RES SMD 1/16W 22K J 0402 RoHS G --
R831 30021989 RES SMD 1/16W 100K J 0402 ROHS G --
R832 30021989 RES SMD 1/16W 100K J 0402 ROHS G --
R833 30022121 RES SMD 1/16W 820R J 0402 ROHS G --
R834 30021958 RES SMD 1/16W 47K J 0402 RoHS G --
R835 30021958 RES SMD 1/16W 47K J 0402 RoHS G --
R836 30021958 RES SMD 1/16W 47K J 0402 RoHS G --
