Sharp LC-40LE530E Service Manual

98
LC-32LE530
LC-40LE530
REF No. PARTS DESCRIPTION *
PRICE
CODE
R837 30021958 RES SMD 1/16W 47K J 0402 RoHS G --
R838 30021958 RES SMD 1/16W 47K J 0402 RoHS G --
R84 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R840 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R841 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R842 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R843 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R844 30021991 RES SMD 1/16W 100R J 0402 ROHS G --
R846 30022084 RES SMD 1/16W 33K J 0402 RoHS G --
R847 30022057 RES SMD 1/16W 22K J 0402 RoHS G --
R848 30049062 RES SMD 1/16W 100K F 0402 RoHS G --
R85 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R850 30022046 RES SMD 1/16W 2.2K J 0402 RoHS G --
R851 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R852 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R853 30022068 RES SMD 1/16W 6.8K F 0402 ROHS G --
R854 30022068 RES SMD 1/16W 6.8K F 0402 ROHS G --
R86 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R88 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R91 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R92 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R93 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R94 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R95 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R96 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
R97 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R98 30021987 RES SMD 1/16W 4.7K J 0402 RoHS G --
R99 30021996 RES SMD 1/16W 10K J 0402 ROHS G --
CN1 30059740 SOCKET D-SUB 15P TOP 11.9MM RoHS G --
CN141 30044670 SOCKET USB SIDE RoHS G --
CN145 30066919 CONN HEADER 6P 2.0MM SIDE W/LOCK RoHS G --
CN147 30070520 CONN FFC LVDS 41P 0.5mm SMDR/A W/PL ROHS G --
CN148 30070519 CONN FFC LVDS 51P 0.5mm SMDR/A W/PL ROHS G --
CN149 30067935 CONN HEADER 2X14P 2.54 W/LOCK SIDE RoHS G --
CN19 30044670 SOCKET USB SIDE RoHS G --
CN23 30066919 CONN HEADER 6P 2.0MM SIDE W/LOCK RoHS G --
CN3 30066018 SOCKET HDMI 19P 0.5MM TOP ROHS G --
CN4 30066018 SOCKET HDMI 19P 0.5MM TOP ROHS G --
CN6 30068682 SOCKET PCMCIA S.DECK 4mm5V W/G W/SHLROHS G --
CN8 30063090 CONN HEADER 5P 2.0MM SIDE W/LOCK RoHS G --
FS4 30028331 FUSE SAFE SMD 7A/32VDC 1206 RoHS G --
JK106 30067506 JACK HEADPHONE BLACK 3 POLE SIDE ROHS G --
JK107 30067216 JACK HEADPHONE YELLOW 3 POLE SIDE ROHS G --
JK4 30061294 JACK RCA 3P WHITE/RED/BLACK TOP ROHS G --
JK5 30061293 JACK RCA 3P GREEN/BLUE/RED TOP ROHS G --
PL1 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs G --
PL2 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs G --
PL3 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs G --
PL4 35028251 GROUND TERMINAL Main Board 8.5X8.3 Rohs G --
S100 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S101 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S102 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S103 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S104 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S106 30022132 RES SMD 1/16W 0R 0402 ROHS G --
MISCELLANEOUS PARTS
REF No. PARTS DESCRIPTION *
PRICE
CODE
S107 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S110 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S111 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S113 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S116 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S117 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S118 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S119 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S123 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S125 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S136 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S138 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S14 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S142 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S147 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S148 30022056 RES SMD 1/16W 220R J 0402 RoHS G --
S15 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S151 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S152 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S153 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S155 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S156 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S161 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S164 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S17 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S170 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S171 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S173 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S180 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S181 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S182 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S184 30022089 RES SMD 1/16W 680R J 0402 RoHS G --
S185 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S186 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S187 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S190 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S192 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S2 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S201 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S202 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S203 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S204 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S206 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S207 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S213 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S214 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S215 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S216 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S217 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S218 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S22 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S224 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S225 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S23 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S234 30022132 RES SMD 1/16W 0R 0402 ROHS G --
S242 30022132 RES SMD 1/16W 0R 0402 ROHS G --
