Sharp LC-40LE730E Service Manual

2
LC-40LE730
LC-46LE730
ELECTRICAL SPECIFICATIONS
Specications
Environmental Specications
*1 Measured according to IEC 62087 Ed. 2.
*2 For further information about the Energy Save function,
please see related pages in this operation manual.
*3 Measured according to IEC 62301 Ed. 1.
*4 Measured according to IEC 62301 Ed. 1.
*5 Annual energy consumption is calculated on the basis
of the On-Mode (HOME MODE) power consumption,
watching TV 4 hours a day, 365 days a year.
*6 Annual energy consumption is calculated on the basis of
the Energy-Save-Mode power consumption, watching TV
4 hours a day, 365 days a year.
NOTE
• The power consumption of On-Mode varies depending on the images the TV displays.
40” 46”
*1 On-Mode (W) (HOME MODE) 48 W 60 W
*2 Energy-Save-Mode (W) ECO 39 W 55 W
*3 Standby-Mode (W) 0.21 W 0.21 W
*4 Off Mode (W) 0.16 W 0.16 W
*5 Annual Energy Consumption (kWh) 70 kWh 88 kWh
*6 Annual Energy Consumption
Energy-Save-Mode (kWh)
ECO 57 kWh 80 kWh
Appendix
Specifications
Item
40” LCD COLOUR TV, Models:
LC-40LE730E, LC-40LE731E, LC-40LE732E
46” LCD COLOUR TV, Models:
LC-46LE730E, LC-46LE731E, LC-46LE732E
LCD Panel 40” BLACK TFT LCD LED TV 46” BLACK TFT LCD LED TV
Resolution 6.220.800 dots (1.920 x 1.080 pixels)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV
Func-
tions
TV Standard Analogue CCIR (B/G, I (LE731 for UK and Ireland only), D/K, L/L’)
Digital DVB-T (2K/8K OFDM)(H.264), DVB-C, DVB-T2 (LE731 only), DVB-S/S2 (LE732 only)
Receiving Channel
VHF/UHF E2–E69 ch, F2–F10 ch, I21–I69 ch, IR A–IR J ch (Digital: IR A ch–E69 ch)
CATV Hyper-band, S1–S41 ch
TV-Tuning System Auto Preset 999 ch: non-Nordic / 9999 ch: Nordic (ATV: 99 ch), Auto Label, Auto Sort
STEREO / BILINGUAL NICAM/A2
Viewing angles H: 176°, V: 176°
Audio Ampli er 10 W + 5 W + 5 W
Speaker Woofer Ø 70 mm, tweeter (Ø 11 mm) x 2
Terminals
TV Antenna UHF/VHF 75 Ω Din type (Analogue & Digital)
SERVICE Ø 3.5 mm jack
SCART SCART (AV input, RGB input, TV output, Y/C input)
PC INPUT VGA (D-Sub 15pin), Ø 3.5 mm jack (shared with HDMI)
COMPONENTS COMPONENT IN: Y/PB(CB)/PR(CR), RCA (AUDIO R/L)
HDMI1 HDMI, Ø 3.5 mm jack (shared with PC INPUT), ARC, 3D.
HDMI2 HDMI, Ø 3.5 mm jack (shared with PC INPUT), 3D.
HDMI3 HDMI, Ø 3.5 mm jack (shared with PC INPUT), 3D.
HDMI4 (Rear) HDMI, Ø 3.5 mm jack (shared with PC INPUT), 3D.
USB 1 (USB REC / Media Player
/ HDD Ready / 3D Glasses
charge)
USB 2.0 HOST (A Type)
USB 2 (Media Player / HDD Ready
3D Glasses charge)
USB 2.0 HOST (A type)
USB 3 (WIFI) USB 2.0 HOST (A type) (Wi-Fi use only)
ETHERNET (10/100) Network connector
AV RCA connector (AV input)
SPDIF OUT Optical S/PDIF digital audio output.
C. I. (Common Interface) EN50221, R206001, CI+ speci cation
Headphones Ø 3.5 mm jack (Audio output)
OSD language
Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian,
Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian, Slovak, Slovene,
Spanish, Swedish, Turkish, Ukrainian, Byelorussian, Romanian, Croatian, Serbian.
Power Requirement AC 220–240 V, 50 Hz
Power Consumption (IEC62087 Method) 102W (0.21 W Standby) 124W (0.21 W Standby)
Weight 12.2 Kg (Without stand), 14.4 Kg (With stand)
16.7Kg (Without stand), 19.7 Kg (With stand)
Operating Temperature 0 °C to +40 °C
41

Sharp LC-40LE730E Specifications

General

Brand	Sharp
Model	LC-40LE730E
Category	LCD TV
Language	English
