Sharp LC-40LE730E Service Manual

76
LC-40LE730
LC-46LE730
PARTS LISTING
REPLACEMENT PARTS
Replacementpartswhichhavespecialsafetycharacteristicsareidentiedinthismanual.
Electricalcomponentshavingsuchfeaturesareidentied by in the Replacement Parts Listing.
The use of a substitute replacement part which does not have the same safety characteristics
as the factory recommended is not permitted.
Replacementpartsnotshowninthisservicemanualmaycreateshockre,orotherhazards.
HOW TO ORDER REPLACEMENT PARTS
To have your order completed promptly and correctly please supply the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO.
4. DESCRIPTION 5. CODE 6. QUANTITY
!
MARK *: SPARE PARTS DELIVERY SECTION
REF No. PARTS DESCRIPTION *
PRICE
CODE
R1LK400D3LB43P 40" LCD MODULE LK400D3LB43 P --
R1LK460D3LB33P 46" LCD MODULE LK460D3LB33 P --
DUNTKF915FM02 MAIN LE730E P CC
! RDENCA440WJQZ POWER WITH LED DRIVER 40" 46" P BN
RUNTKA880WJP2 CONTROL BUTTON UNIT LE730E P BC
IC 0503 VHIR24002AS-1Y CI EPROM R1EX24002ASAS0A P AB
IC 0552 VHINJM4565V-1Y IC NJM4565V-TE1 P AC
IC 1105 VHIS172B33E-1Y CI S-1172B33-E6T1G P AC
IC 1505 VHIBU16028K-1Q CI BU16028KV P AH
IC 1506 VHITC7SH08U-1Y CI TC7SH08FU(TE85L) P --
IC 2701 VHISTA333BW-1L CI STA333BW13TR P AL
IC 2702 VHIBH3547F+-1L CI BH3547-E2 P AC
IC 3301 RH-IXD425WJZZQ IC SUPRA HD ZR39691HGCG-X TRAY ZORAN P BE
IC 3501 RH-IXD242WJQZQ CI K4B2G1646C-HCH9 DDR3-2G-1333 SAMSUNG P BA
IC 3502 RH-IXD242WJQZQ CI K4B2G1646C-HCH9 DDR3-2G-1333 SAMSUNG P BA
IC 3503 RH-IXD362WJZZY IC RT9199GSP DDR3 BUS TERM.REG(RICHTEK) P AE
IC 3601 RH-IXC768WJQZQ IC H5PS5162FFR-G7C P AQ
IC 3701 RH-IXD378WJZZQ IC SUPRA FRC ZR39301BGCG-TRAY ZORAN P BB
IC 3702 RH-IXD084WJZZY IC W25X20BVSNIG P AE
IC 4401 VHITC7SH17U-1Y CI TC7SH17FU(TE85L,F) P AC
IC 4403 VHIS170B50U-1Y CI S-1170B50UC-0UJTFG P AD
IC 4404 VHILCX373FK-1Y CI TC74LCX373FK(EJK) P AC
IC 8401 RH-IXD352WJN1Q MICRON MT29F1G08ABADAWP:D 1Gb NAND+SOFT P AT
IC 9501 RH-IXD309WJZZY IC IP101A LF CI+ FAST ETHERNET TRANCEIVE P AF
IC 9551 RH-IXD187WJZZY CI AAT4614IGU-2-T1 ANALOGIC TECH P AC
IC 9552 VHI2514BAEZ-1Q IC USB2514B-AEZG P AM
IC 9553 VHIS170B50U-1Y CI S-1170B50UC-0UJTFG P AD
IC 9601 VHIBD9329EF-1Y CI BD9329EFJ-E2 P AF
IC 9602 VHIMP28254+-1Y CI MP28254EL-LF-Z P AF
IC 9603 VHIBD3552HF-1L IC BD3552HFN-TR P AH
IC 9604 VHIS172B34E-1Y IC S-1172B34-E6T1G P AC
IC 9605 VHIS135B11M-1Y IC S-1135B11-M5T1S P --
IC 9606 VHIS135B12M-1Y IC S-1135B12-M5T1S P --
IC 9607 VHIS135B11M-1Y IC S-1135B11-M5T1S P --
IC 9608 VHIS135B33M-1Y IC S-1135B33-M5T1S P --
IC 9609 VHITC7SH17U-1Y CI TC7SH17FU(TE85L,F) P AC
IC 9701 VHIBD9329EF-1Y CI BD9329EFJ-E2 P AF
IC 9702 VHIBD3552HF-1L IC BD3552HFN-TR P AH
Q 0501 VSRT1N441U/-1Y TRT RT1N441U-T111-1 P AA
Q 0552 VSIMH23T110-1Y TRT IMH23T110 P AC
Q 1501 VS2SC3928AR-1Y TRT 2SC3928AR-T112-1R MITSUBISHI P AA
TRANSISTORS
INTEGRATED CIRCUITS
LCD PANEL
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY
PRINTED WIRING BOARDS
DUNTKF915WE02
LE730 -MAIN Unit
REF No. PARTS DESCRIPTION *
PRICE
CODE
Q 1505 VS2N7002K++-1Y TRT 2N7002K-RTK/P P AA
Q 2601 VS2SC3928AR-1Y TRT 2SC3928AR-T112-1R MITSUBISHI P AA
Q 2602 VS2SC3928AR-1Y TRT 2SC3928AR-T112-1R MITSUBISHI P AA
Q 2604 RH-TXA064WJZZY TRT AO3415 P-Channel Mosfet ALPHA & OMEG P AC
Q 2703 VSISA1530AC-1Y DIGITAL TRANSISTOR ISA1530AC1-T112-1R P AA
Q 2705 VSRT1N141U/-1Y TRT RT1N141U-T111-1 P AA
Q 2706 VSIMH23T110-1Y TRT IMH23T110 P AC
Q 3401 VS2SC3928AR-1Y TRT 2SC3928AR-T112-1R MITSUBISHI P AA
Q 3405 VS2N7002K++-1Y TRT 2N7002K-RTK/P P AA
Q 4401 VSRT1N441U/-1Y TRT RT1N441U-T111-1 P AA
Q 9501 VSRT1N441U/-1Y TRT RT1N441U-T111-1 P AA
Q 9602 VSKN3904S//-1+ TRT KN3904S-RTK/P P AA
Q 9603 VS2SC3928AR-1Y TRT 2SC3928AR-T112-1R MITSUBISHI P AA
Q 9604 RH-TXA064WJZZY TRT AO3415 P-Channel Mosfet ALPHA & OMEG P AC
D 0501 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 0502 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 0503 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 0504 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 0505 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 0529 VHDDAN202K/-1Y DIODO DAN202KT146 P AA
D 0536 VHPGPFMV51T-1 PHOTODIODO GP1FV51TK0F P AF
D 0556 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 0557 RH-EXA629WJQZY ZENER DIODE 3,9V RKZ3,9B2KG P AA
D 1501 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 1502 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 1503 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 1504 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 1505 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 1506 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 1507 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 1508 RH-EXA741WJQZY ZENER DIODE DZ2J056M0L P AC
D 1509 VHDRB520S30-1Y DIODO RB520S-30 P AA
D 2702 VHDHSU119//-1Y DIODO HSU119TRF P AB
D 2703 VHDHSU119//-1Y DIODO HSU119TRF P AB
D 2706 VHDHSU119//-1Y DIODO HSU119TRF P AB
D 2707 VHDHSU119//-1Y DIODO HSU119TRF P AB
D 3401 VHDHSU119//-1Y DIODO HSU119TRF P AB
D 4401 VHDDAN202K/-1Y DIODO DAN202KT146 P AA
D 9551 RH-DXA159WJZZY DIODE RF201L2STE25 ROHM P AC
D 9601 VHDHSU119//-1Y DIODO HSU119TRF P AB
SG 0501 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0502 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0503 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0551 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0552 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0553 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0554 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0555 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0556 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0557 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0558 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0559 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0560 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0561 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0562 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0563 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0564 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
SG 0565 RH-VXA187WJQZY VARISTOR EZAEG2A50AX P AD
VA 1501 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 1502 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 1503 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 1504 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 1505 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 1506 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 1507 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 1508 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 9551 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 9552 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 9553 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
DIODES
PACKAGED CIRCUITS
