Sharp LC-40LE730E - Page 77

77
LC-40LE730
LC-46LE730
REF No. PARTS DESCRIPTION *
PRICE
CODE
VA 9554 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 9555 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
VA 9556 RH-VXA074WJZZY VARISTOR AVRL101A1R1NTB P AD
X 3301 RCRSCA219WJQZY CRYISTAL NX5032GA(EXS00A-CG01569) P AF
X 3701 RCRSCA219WJQZY CRYISTAL NX5032GA(EXS00A-CG01569) P AF
X 9551 RCRSCA224WJZZY CRYSTAL AT-41CD2-24.000MHz_20_N_NDK P AC
FB 0501 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 0502 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 0503 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 0504 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 0505 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 0506 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 0507 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 0508 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 0512 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 1109 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 1111 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 1112 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 1113 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 1114 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 1115 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 1501 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2603 RBLN-A528WJZZY FERRITA HI0805N600R-10 P AA
FB 2702 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2703 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2704 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2705 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2706 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2707 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2708 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2709 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2711 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 2712 RBLN-A528WJZZY FERRITA HI0805N600R-10 P AA
FB 3401 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3403 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3404 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3405 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3406 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3407 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3408 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3409 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3410 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3411 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3412 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3413 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3414 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3415 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3416 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3417 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3418 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3419 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3420 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3421 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD P AA
FB 3422 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3501 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3502 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD P AA
FB 3601 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3701 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 3702 RBLN-A528WJZZY FERRITA HI0805N600R-10 P AA
FB 3703 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 4402 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9501 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9502 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9503 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9504 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9552 RBLN-A528WJZZY FERRITA HI0805N600R-10 P AA
FB 9553 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9554 RBLN-A528WJZZY FERRITA HI0805N600R-10 P AA
FB 9601 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9602 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9603 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
COILS AND FILTERS
REF No. PARTS DESCRIPTION *
PRICE
CODE
FB 9604 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9605 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9606 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9607 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9609 RBLN-A528WJZZY FERRITA HI0805N600R-10 P AA
FB 9610 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD P AA
FB 9611 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9612 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD P AA
FB 9613 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9614 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9615 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9616 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9617 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9618 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9701 RBLN-A528WJZZY FERRITA HI0805N600R-10 P AA
FB9608 VRS-TV1JD000JY RES 2125 0 OHM 5% 1/10W SMD P AA
L 1101 VPDBNR33JR45NY BOBINA NLV25T-R33J-PF P AB
L 1102 VPDBNR33JR45NY BOBINA NLV25T-R33J-PF P AB
L 2601 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2602 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2603 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2604 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2605 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2606 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2607 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2608 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2609 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2610 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2611 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2612 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2613 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2614 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2615 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2616 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2617 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2618 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2619 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2620 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2621 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2622 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2623 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2624 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2701 RCILPB016WJQZY COIL SWPA6045S220 P AD
L 2702 RCILPB016WJQZY COIL SWPA6045S220 P AD
L 2703 RCILPB016WJQZY COIL SWPA6045S220 P AD
L 2704 RCILPB016WJQZY COIL SWPA6045S220 P AD
L 3301 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3302 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3303 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3304 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3305 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3306 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3337 VPDBN1R8J1R1NY BOBINA NLV25T-1R8J-PF P AB
L 3338 VPDBN1R8J1R1NY BOBINA NLV25T-1R8J-PF P AB
L 9551 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 9552 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 9553 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 9554 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 9601 RCILPB014WJQZY COIL SWPA6045S100 P AC
L 9602 RCILPB011WJQZY COIL SWPA6045S2R7 P AB
L 9701 RCILPB014WJQZY COIL SWPA6045S100 P AC
TU 1101 RTUDAA082WJQZ TUNER FK1602 LOW IF DVB-T/T2/C NUTUNE P AR
C 0501 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 0502 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0503 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0504 VCCCCZ1HH561JY CERAM C 0402 560PF 50V 5% P AA
C 0505 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0506 VCCCCZ1HH561JY CERAM C 0402 560PF 50V 5% P AA
C 0507 VCCCCY1HH101JY CONDENSADOR GRM39CK 101J 50 (1608)SMD P AA
TUNER
CAPACITORS
