LC-40LE730
LC-46LE730
46
46” OVERALL WIRING DIAGRAMS
LC-46L*73*E*
2 / 5
Service Manual
3. Disconnect all the connectors from all the PWBs.
SPEAKER
(SUBWOOFER)
TO DISPLAY
SUPPLY
[EL]
AC CORD
[RA]
[PD]
[SP]
[SB]
[PD]
[LV]
[LW]
SPEAKER -L
(TWEETER)
SPEAKER -R
(TWEETER)
[LV]
[LW]
P802
P801
SC101
[BL]
LW QCNW-M367WJQZ
LV QCNW-M365WJQZ
PD QCNW-M004WJQZ
AC CORD QACCKA058WJPZ
WIRES
POWER SUPPLY RDENCA440WJQZ
MAIN BOARD DUNTKF915FM02
PANEL R1LK460D3LB33P
SPEAKER TWEETER RSP-ZA550WJZZ
SPEAKER SUBWOOFER RSP-ZA549WJZZ
OTHER
