Sharp LC-40LE730E Service Manual

27
LC-40LE730
LC-46LE730
3. Remote control key operation and description of display in adjustment process mode.
1. key operation
Remote control key Keyboard unit Function
Cursor(▼/▲) P (
s/r) Movinganitem(line)byone(up/down)on“SharpFactoryMenu”
or submenus.
OK
b
Selectingasubmenuonlines5to12of“SharpFactoryMenu”or
executingafunction.
Cursor(◄/►) V (+/-) Changing a selected item setting value.
MENU MENU Exitofadjustmentmode.
Returnto“SharpFactoryMenu”fromasubmenu.
The required input mode should be switched previously to enter the Service Mode.
CAUTION: Use due care in handling the information described here lest the users should know how to enter the
adjustment process mode. If the settings are tampered with in this mode, unrecoverable system
damage may result.
4. Description of display
Figure 1: Main Service Adjustment Menu
← Informative (Main microprocessor version).
← Informative.
← Informative (Remote Control/Keyboard…).
← Press “OK” to go to INIT submenu.
← Press “OK” to go to ETC submenu.
← Press “OK” to go to PUBLIC MODE submenu.
← Press “OK” to go to SMARTLOADER submenu.
← Press “OK” to go to ADC ADJUST submenu.
← Press “OK” to go to GAMMA submenu.
← Press “OK” to go to SYSTEM INFORMATION submenu.
← Informative (Main microprocessor version).← Informative (Main microprocessor version).
← Informative.← Informative.
← Informative (Remote Control/Keyboard…).← Informative (Remote Control/Keyboard…).
← Press “OK” to go to INIT submenu.← Press “OK” to go to INIT submenu.
← Press “OK” to go to ETC submenu.← Press “OK” to go to ETC submenu.
← Press “OK” to go to PUBLIC MODE submenu.← Press “OK” to go to PUBLIC MODE submenu.
← Press “OK” to go to SMARTLOADER submenu.← Press “OK” to go to SMARTLOADER submenu.
← Press “OK” to go to ADC ADJUST submenu.← Press “OK” to go to ADC ADJUST submenu.
← Press “OK” to go to GAMMA submenu.← Press “OK” to go to GAMMA submenu.
← Press “OK” to go to SYSTEM INFORMATION submenu.← Press “OK” to go to SYSTEM INFORMATION submenu.
SHARP FACTORY MENU
Main version
LE730E v1.253 790.173.78 v14
FRC 2.3.0.180.390.290
Hardware SHARP 691
Normal standby cause Remote control
INIT
ETC
PUBLIC MODE
SMARTLOADER
ADC ADJUST
GAMMA
SYSTEM INFORMATION
No. Description Displayspecication
(1) Service Information Current Software version and others.
(2) Item name Submenustobecheckedoradjusted(bypressing“OK”button)
(3) Factory init and Inch setting Are shown on INIT submenu
(2)
(3)
(1)
