Sharp LC-40LE730E Service Manual

78
LC-40LE730
LC-46LE730
REF No. PARTS DESCRIPTION *
PRICE
CODE
C 0508 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0510 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0512 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0513 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0514 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0515 VCKYCZ1HB472KY C CERAM 0402 4,7NF 50V 10% P AA
C 0516 VCKYCZ1AB474KY C CERAM 0402 470NF 10V 10% P AB
C 0517 VCKYCZ1AB474KY C CERAM 0402 470NF 10V 10% P AB
C 0537 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 0538 VCCCCZ1HH220JY CERAM C 0402 22PF 50V 5% P AA
C 0539 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 0554 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0555 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0557 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0558 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0559 VCCCCZ1HH470JY CERAM C 0402 47PF 50V 5% P AA
C 0560 VCCCCZ1HH470JY CERAM C 0402 47PF 50V 5% P AA
C 0561 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0562 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0563 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0566 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 0568 VCEASX1CN107MY C ELEC 100UF 16V MVL16VC100MF80E1 P AD
C 0572 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0573 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0574 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0575 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0576 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0577 VCAAPE0JJ227MY C ELEC 220UF 20% 6,3V 6SVP100M P AH
C 0580 VCCCCZ1HH271JY C CERAM 0402 270PF 50V 5% P AA
C 0581 VCKYCZ1HB471KY C CERAM 0402 470PF 50V 10% P AA
C 0582 VCKYCZ1HB471KY C CERAM 0402 470PF 50V 10% P AA
C 0585 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0586 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0587 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0588 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0589 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0590 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0591 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0592 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0593 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0594 VCCCCZ1HH561JY CERAM C 0402 560PF 50V 5% P AA
C 0595 VCCCCZ1HH561JY CERAM C 0402 560PF 50V 5% P AA
C 0596 VCCCCZ1HH680JY C CERAM 0402 68PF 50V 5% P AA
C 0597 VCCCCZ1HH561JY CERAM C 0402 560PF 50V 5% P AA
C 0598 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0599 VCCCCZ1HH680JY C CERAM 0402 68PF 50V 5% P AA
C 0600 VCCCCZ1HH470JY CERAM C 0402 47PF 50V 5% P AA
C 0601 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0602 VCKYCZ1HB472KY C CERAM 0402 4,7NF 50V 10% P AA
C 0603 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0604 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0605 VCKYCZ1AB474KY C CERAM 0402 470NF 10V 10% P AB
C 0606 VCKYCZ1AB474KY C CERAM 0402 470NF 10V 10% P AB
C 0607 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0608 VCCCCZ1HH561JY CERAM C 0402 560PF 50V 5% P AA
C 0609 VCKYCZ1AB474KY C CERAM 0402 470NF 10V 10% P AB
C 0610 VCKYCZ1AB474KY C CERAM 0402 470NF 10V 10% P AB
C 0611 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 1107 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1135 VCCCCZ1HH150JY C CERAM 0402 15PF 50V 5% P AA
C 1141 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1144 VCCCCZ1HH150JY C CERAM 0402 15PF 50V 5% P AA
C 1145 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 1148 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 1150 VCEASY0JN477MY C ELEC 470UF 6,3V MLA6,3VC470MF80 P AF
C 1151 VCCCCZ1HH220JY CERAM C 0402 22PF 50V 5% P AA
C 1152 VCKYCZ1HB472KY C CERAM 0402 4,7NF 50V 10% P AA
C 1153 VCCCCZ1HH220JY CERAM C 0402 22PF 50V 5% P AA
C 1154 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 1160 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1161 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 1162 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 1166 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
REF No. PARTS DESCRIPTION *
PRICE
CODE
C 1167 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1170 VCKYCZ1HB471KY C CERAM 0402 470PF 50V 10% P AA
C 1501 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1502 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1503 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1504 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1505 VCKYCZ0JF105ZY C CERAM 0402 1uF 6,3V 20% P AD
C 1506 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1507 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 1508 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1509 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 1511 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1512 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 1513 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1514 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 1517 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 1518 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1519 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 1520 VCEASK0JN227MY C ELEC 220UF 20% 6,3V MVY6,3VC220MF60 P AC
C 1521 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2605 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 2606 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2607 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2608 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 2609 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2702 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 2703 VCKYTV1CB104KY C CERAM 100NF 16V 2125SMD P AB
C 2704 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 2705 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 2706 VCKYCZ1HB472KY C CERAM 0402 4,7NF 50V 10% P AA
C 2707 VCCCCZ1HH101JY C CERAM 0402 100PF 50V 5% P AA
C 2708 VCCCCZ1HH681JY C CERAM 0402 680PF 50V 5% P AA
C 2709 VCKYTV1CB104KY C CERAM 100NF 16V 2125SMD P AB
C 2710 VCKYTV1CB104KY C CERAM 100NF 16V 2125SMD P AB
C 2711 VCKYTV1CB104KY C CERAM 100NF 16V 2125SMD P AB
C 2712 VCKYTV1CB104KY C CERAM 100NF 16V 2125SMD P AB
C 2713 VCKYTV1CB104KY C CERAM 100NF 16V 2125SMD P AB
C 2714 RC-KZA621WJQZY C CERAM 1uF 25V TMK107BJ105KAFT P AA
C 2715 VCKYTV1CB104KY C CERAM 100NF 16V 2125SMD P AB
C 2716 RC-KZA621WJQZY C CERAM 1uF 25V TMK107BJ105KAFT P AA
C 2717 VCKYCZ1HB331KY C CERAM 0402 330PF 50V 10% P AA
C 2718 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2719 VCKYCZ0JF105ZY C CERAM 0402 1uF 6,3V 20% P AD
C 2720 VCKYCZ0JF105ZY C CERAM 0402 1uF 6,3V 20% P AD
C 2721 VCKYCZ1HB331KY C CERAM 0402 330PF 50V 10% P AA
C 2722 RC-KZA116WJZZY C CERAM 4,7UF 6,3V GRM188B30J475KE18D P AD
C 2723 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 2724 VCEASX1CN476MY C ELEC 47UF 16V MVL16VC47MF60E1 P AD
C 2725 RC-EZ1339CEZZY C ELEC 220UF 16V P AF
C 2726 RC-EZ1339CEZZY C ELEC 220UF 16V P AF
C 2727 VCCCCZ1HH220JY CERAM C 0402 22PF 50V 5% P AA
C 2728 VCCCCZ1HH220JY CERAM C 0402 22PF 50V 5% P AA
C 2729 RC-EZ1339CEZZY C ELEC 220UF 16V P AF
C 2730 VCKYCZ1HB331KY C CERAM 0402 330PF 50V 10% P AA
C 2731 VCKYCZ1HB331KY C CERAM 0402 330PF 50V 10% P AA
C 2732 VCKYCZ1HB331KY C CERAM 0402 330PF 50V 10% P AA
C 2733 VCKYCZ1AB474KY C CERAM 0402 470NF 10V 10% P AB
C 2734 VCKYTV1CB684KY C CERAM 680NF 16V 2125SMD P AB
C 2735 VCKYTV1CB684KY C CERAM 680NF 16V 2125SMD P AB
C 2736 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2737 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2738 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2739 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2740 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2741 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2742 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 2743 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 2744 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2745 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 2746 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 2747 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 2748 VCKYCZ1HB102KY C CERAM 0402 1NF 50V 10% P AA
C 2749 RC-EZ1339CEZZY C ELEC 220UF 16V P AF
