LC-40LE730
LC-46LE730
2. Removing of major Parts 46”
LC-46L*73*E*
1 / 5
LC32D44E-BK
Service Manual
CHAPTER 2. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Remove the 4 lock screws and detach the Stand.
2. Remove the 14 lock screws , 1 lock screw and detach the Rear Cabinet.
Stand
2
1
3
Rear
Cabinet
Front Cabinet
2
1
3
