Sharp LC-40LE730E Service Manual

29
LC-40LE730
LC-46LE730
Page Line
Sub
page
Item Description Remarks (adjustment details, etc.)
G-GAIN 269 Only for Engineering purpose (Please don’t use)
B-GAIN 272 Only for Engineering purpose (Please don’t use)
R-OFFSET 2019 Only for Engineering purpose (Please don’t use)
G-OFFSET 2044 Only for Engineering purpose (Please don’t use)
B-OFFSET 2019 Only for Engineering purpose (Please don’t use)
AUTO ADC ► Only for Engineering purpose (Please don’t use)
10 GAMMA GAMMA Submenu Press “►” or “OK” to enter to GAMMA Submenu
7/8
MGAMMA IN1 40 W/B adjustment, gradation 1 input setting.
MGAMMA IN2 80 W/B adjustment, gradation 2 input setting.
MGAMMA IN3 120 W/B adjustment, gradation 3 input setting.
MGAMMA IN4 160 W/B adjustment, gradation 4 input setting.
MGAMMA IN5 200 W/B adjustment, gradation 5 input setting.
MGAMMA IN6 240 W/B adjustment, gradation 6 input setting.
Pattern 0 Selection of internal pattern from 0 to 6
MGAMMA R1
40 inch / 46 inch
205 /168
W/B adjustment, gradation 1R adjustment value.
MGAMMA G1 193 / 163 W/B adjustment, gradation 1G adjustment value.
MGAMMA B1 207 / 166 W/B adjustment, gradation 1B adjustment value.
MGAMMA R2 373 / 339 W/B adjustment, gradation 2R adjustment value.
MGAMMA G2 360 / 328 W/B adjustment, gradation 2G adjustment value.
MGAMMA B2 371 / 327 W/B adjustment, gradation 2B adjustment value.
MGAMMA R3 537 / 511 W/B adjustment, gradation 3R adjustment value.
MGAMMA G3 532 / 497 W/B adjustment, gradation 3G adjustment value.
MGAMMA B3 534 / 494 W/B adjustment, gradation 3R adjustment value.
MGAMMA R4 692 / 670 W/B adjustment, gradation 4R adjustment value.
MGAMMA G4 691 / 651 W/B adjustment, gradation 4G adjustment value.
MGAMMA B4 689 / 651 W/B adjustment, gradation 4B adjustment value.
MGAMMA R5 837 / 823 W/B adjustment, gradation 5R adjustment value.
MGAMMA G5 837 / 799 W/B adjustment, gradation 5G adjustment value.
MGAMMA B5 831 / 800 W/B adjustment, gradation 5B adjustment value.
MGAMMA R6 972 / 971 W/B adjustment, gradation 6R adjustment value.
MGAMMA G6 970 / 945 W/B adjustment, gradation 6G adjustment value.
MGAMMA B6 957 / 937 W/B adjustment, gradation 6R adjustment value.
Commit ► Press “►” for EEP writing of adjustment values.
11
SYSTEM
INFORMATION
SYSTEM INFORMATION
Submenu
Press “►” or “OK” to enter to SYSTEM
INFORMATION Submenu (Only for Engineering
purpose, don’t use)
8/8
NOISE LEVEL 0 Informative. Only for Engineering purpose.
GLOBAL MOTION 0 Informative. Only for Engineering purpose.
BIT RATE 0 Informative. Only for Engineering purpose.
VPS code 0x0 Informative. Only for Engineering purpose.
830/1 code 0x0 Informative. Only for Engineering purpose.
830/2 code 0x0 Informative. Only for Engineering purpose.
5. Adjustment process mode menu (continued)
