Sharp LC-40LE730E Service Manual

81
LC-40LE730
LC-46LE730
REF No. PARTS DESCRIPTION *
PRICE
CODE
C 9618 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 9619 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9620 VCCCCZ1HH150JY C CERAM 0402 15PF 50V 5% P AA
C 9621 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 9622 RC-KZA385WJZZY C CERAM 22UF 6,3V JMK212BJ226KG-T P AE
C 9623 RC-KZA385WJZZY C CERAM 22UF 6,3V JMK212BJ226KG-T P AE
C 9624 VCKYCY0JB105KY CONDENSADOR GRM39B 105K 6.3 (1608)SMD P AB
C 9626 RC-KZA385WJZZY C CERAM 22UF 6,3V JMK212BJ226KG-T P AE
C 9627 RC-KZA385WJZZY C CERAM 22UF 6,3V JMK212BJ226KG-T P AE
C 9628 VCKYCZ1HB332KY C CERAM 0402 3,3NF 50V 10% P AA
C 9629 VCKYCZ1EB103KY C CERAM 0402 10NF 25V 10% P AA
C 9630 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 9631 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 9632 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9633 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9634 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9635 VCAAPE0JJ227MY C ELEC 220UF 20% 6,3V 6SVP100M P AH
C 9636 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9637 RC-KZA116WJZZY C CERAM 4,7UF 6,3V GRM188B30J475KE18D P AD
C 9638 VCKYCY0JB105KY CONDENSADOR GRM39B 105K 6.3 (1608)SMD P AB
C 9639 RC-KZA116WJZZY C CERAM 4,7UF 6,3V GRM188B30J475KE18D P AD
C 9640 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9641 RC-KZA116WJZZY C CERAM 4,7UF 6,3V GRM188B30J475KE18D P AD
C 9642 VCKYCY0JB105KY CONDENSADOR GRM39B 105K 6.3 (1608)SMD P AB
C 9643 RC-KZA116WJZZY C CERAM 4,7UF 6,3V GRM188B30J475KE18D P AD
C 9644 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9645 RC-KZA116WJZZY C CERAM 4,7UF 6,3V GRM188B30J475KE18D P AD
C 9646 VCKYCY0JB105KY CONDENSADOR GRM39B 105K 6.3 (1608)SMD P AB
C 9647 RC-KZA116WJZZY C CERAM 4,7UF 6,3V GRM188B30J475KE18D P AD
C 9648 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9649 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 9650 VCKYCY0JB105KY CONDENSADOR GRM39B 105K 6.3 (1608)SMD P AB
C 9651 RC-KZA116WJZZY C CERAM 4,7UF 6,3V GRM188B30J475KE18D P AD
C 9652 VCKYCZ1CB103KY C CERAM 0402 10NF 16V 10% P AA
C 9653 RC-KZA385WJZZY C CERAM 22UF 6,3V JMK212BJ226KG-T P AE
C 9654 VCKYCZ1HB472KY C CERAM 0402 4,7NF 50V 10% P AA
C 9655 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9656 VCKYCY0JB105KY CONDENSADOR GRM39B 105K 6.3 (1608)SMD P AB
C 9658 RC-KZA385WJZZY C CERAM 22UF 6,3V JMK212BJ226KG-T P AE
C 9659 VCKYCZ1EB103KY C CERAM 0402 10NF 25V 10% P AA
C 9660 VCKYCZ1HB332KY C CERAM 0402 3,3NF 50V 10% P AA
C 9661 RC-KZA385WJZZY C CERAM 22UF 6,3V JMK212BJ226KG-T P AE
C 9662 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9664 VCAAPE0JJ227MY C ELEC 220UF 20% 6,3V 6SVP100M P AH
C 9665 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 9701 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 9702 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 9703 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 9704 RC-KZA388WJZZY C CERAM 10uF 6,3V GRM188B30J106ME69D P AM
C 9705 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 9706 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 9707 VCKYCZ1CB682KY C CERAM 0402 6,8NF 16V 10% P AA
C 9708 VCKYCZ1CF103ZY C CERAM 0402 10NF 16V 20% P AA
C 9709 VCCCCZ1HH220JY CERAM C 0402 22PF 50V 5% P AA
R 0502 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 0503 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 0504 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 0505 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 0506 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 0508 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 0509 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 0510 VRS-CZ1JF123JY RES 0402 12KOHM 5% 1/16W SMD P AA
R 0511 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0512 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0513 VRS-CZ1JF102JY RES 0402 1KOHM 5% 1/16W SMD P AA
R 0514 VRS-CZ1JF332JY RES 0402 3,3KOHM 5% 1/16W SMD P AA
R 0515 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0516 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0517 VRS-CZ1JF182JY RES 0402 1,8KOHM 5% 1/16W SMD P AA
R 0518 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0519 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
RESISTORS
REF No. PARTS DESCRIPTION *
PRICE
CODE
R 0551 VRS-CZ1JF221JY RES 0402 220 OHM 5% 1/16W SMD P AA
R 0552 VRS-CZ1JF221JY RES 0402 220 OHM 5% 1/16W SMD P AA
R 0555 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD P AA
R 0556 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD P AA
R 0557 VRS-CZ1JF100JY RES 0402 10 OHM 5% 1/16W SMD P AA
R 0558 VRS-CZ1JF100JY RES 0402 10 OHM 5% 1/16W SMD P AA
R 0561 VRS-CZ1JF223JY RES 0402 22KOHM 5% 1/16W SMD P AA
R 0562 VRS-CZ1JF223JY RES 0402 22KOHM 5% 1/16W SMD P AA
R 0563 VRS-CZ1JF223JY RES 0402 22KOHM 5% 1/16W SMD P AA
R 0565 VRS-CZ1JF223JY RES 0402 22KOHM 5% 1/16W SMD P AA
R 0567 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 0568 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 0569 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 0572 VRS-CZ1JF471JY RES 0402 470 OHM 5% 1/16W SMD P AA
R 0573 VRS-CZ1JF471JY RES 0402 470 OHM 5% 1/16W SMD P AA
R 0574 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 0575 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 0576 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 0577 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 0578 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0579 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0580 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0581 VRS-CZ1JF3R3JY RES 0402 3,3 OHM 5% 1/16W SMD P AA
R 0582 VRS-CZ1JF123JY RES 0402 12KOHM 5% 1/16W SMD P AA
R 0584 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0585 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0586 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0589 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0590 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 0591 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 0592 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0593 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0594 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0595 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 0596 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 0597 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0598 VRS-CZ1JF510JY RES 0402 51 OHM 5% 1/16W SMD P AA
R 0599 VRS-CZ1JF123JY RES 0402 12KOHM 5% 1/16W SMD P AA
R 0600 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0601 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0602 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0603 VRS-CZ1JF470JY RES 0402 47 OHM 5% 1/16W SMD P AA
R 0604 VRS-CZ1JF240JY RES 0402 24 OHM 5% 1/16W SMD P AA
R 0605 VRS-CZ1JF123JY RES 0402 12KOHM 5% 1/16W SMD P AA
R 0606 VRS-CZ1JF123JY RES 0402 12KOHM 5% 1/16W SMD P AA
R 0607 VRS-CZ1JF100JY RES 0402 10 OHM 5% 1/16W SMD P AA
R 0608 VRS-CZ1JF113JY RES 0402 11KOHM 5% 1/16W SMD P AA
R 0609 VRS-CZ1JF102JY RES 0402 1KOHM 5% 1/16W SMD P AA
R 0610 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 0611 VRS-CZ1JF123JY RES 0402 12KOHM 5% 1/16W SMD P AA
R 0612 VRS-CZ1JF100JY RES 0402 10 OHM 5% 1/16W SMD P AA
R 0614 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD P AA
R 0615 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD P AA
R 1104 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 1106 VRS-CZ1JF202JY RES 0402 2KOHM 5% 1/16W SMD P AA
R 1107 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 1108 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 1125 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 1136 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 1501 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 1502 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 1503 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 1504 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 1505 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 1506 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 1507 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 1508 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 1509 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 1510 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 1511 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 1512 VRS-CZ1JF473JY RES 0402 47KOHM 5% 1/16W SMD P AA
R 1514 VRS-CZ1JF750JY RES 0402 75 OHM 5% 1/16W SMD P AA
R 1515 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
