Sharp LC-40LE730E Service Manual

84
LC-40LE730
LC-46LE730
REF No. PARTS DESCRIPTION *
PRICE
CODE
R 9566 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9567 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9568 VRS-CZ1JF103FY RES 0402 10KOHM 1% 1/16W SMD P AA
R 9569 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9570 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD P AA
R 9571 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9573 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD P AA
R 9607 VRS-CZ1JF220JY RES 0402 22 OHM 5% 1/16W SMD P AA
R 9608 VRS-CZ1JF472JY RES 0402 4,7KOHM 5% 1/16W SMD P AA
R 9609 VRS-CZ1JF331JY RES 0402 330 OHM 5% 1/16W SMD P AA
R 9610 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9611 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9612 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9613 VRS-CZ1JF102FY RES 0402 1KOHM 1% 1/16W SMD P AA
R 9615 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9616 VRS-CZ1JF332FY RES 0402 3,3KOHM 1% 1/16W SMD P AA
R 9617 VRS-CZ1JF242JY RES 0402 2,4KOHM 5% 1/16W SMD P AA
R 9618 VRS-CZ1JF153FY RES 0402 15KOHM 1% 1/16W SMD P AA
R 9619 VRS-CZ1JF220JY RES 0402 22 OHM 5% 1/16W SMD P AA
R 9620 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9621 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9622 VRS-CZ1JF183FY RES 0402 18KOHM 1% 1/16W SMD P AA
R 9623 VRS-CZ1JF393FY RES 0402 39KOHM 1% 1/16W SMD P AA
R 9624 VRS-CZ1JF561JY RES 0402 560 OHM 5% 1/16W SMD P AA
R 9625 VRS-CZ1JF102JY RES 0402 1KOHM 5% 1/16W SMD P AA
R 9627 VRS-CZ1JF132FY RES 0402 1,3KOHM 1% 1/16W SMD P AA
R 9628 VRS-CZ1JF102FY RES 0402 1KOHM 1% 1/16W SMD P AA
R 9629 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9630 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9631 VRS-CZ1JF104JY RES 0402 100KOHM 5% 1/16W SMD P AA
R 9632 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9633 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9634 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9635 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9636 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9637 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9638 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9639 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9640 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9643 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9644 VRS-CZ1JF471JY RES 0402 470 OHM 5% 1/16W SMD P AA
R 9645 VRS-CZ1JF471JY RES 0402 470 OHM 5% 1/16W SMD P AA
R 9646 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 9647 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 9649 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
R 9650 VRS-CZ1JF102JY RES 0402 1KOHM 5% 1/16W SMD P AA
R 9652 VRS-CZ1JF182FY RES 0402 1,8KOHM 1% 1/16W SMD P AA
R 9653 VRS-CZ1JF102FY RES 0402 1KOHM 1% 1/16W SMD P AA
R 9657 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9660 VRS-CZ1JF223JY RES 0402 22KOHM 5% 1/16W SMD P AA
R 9661 VRS-CZ1JF682JY RES 0402 6,8KOHM 5% 1/16W SMD P AA
R 9701 VRS-CZ1JF000JY RES 0402 0 OHM 5% 1/16W SMD P AA
R 9702 VRS-CZ1JF181JY RES 0402 180 OHM 5% 1/16W SMD P AA
R 9703 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9704 VRS-CZ1JF332FY RES 0402 3,3KOHM 1% 1/16W SMD P AA
R 9705 VRS-CZ1JF392JY RES 0402 3,9KOHM 5% 1/16W SMD P AA
R 9706 VRS-CZ1JF153FY RES 0402 15KOHM 1% 1/16W SMD P AA
R 9707 VRS-CZ1JF103JY RES 0402 10KOHM 5% 1/16W SMD P AA
R 9708 VRS-CZ1JF620FY RES 0402 62 OHM 1% 1/16W SMD P AA
R 9709 VRS-CZ1JF101JY RES 0402 100 OHM 5% 1/16W SMD P AA
T 9501 RTRNZA129WJQZY TRANSFORMER TLA-6T214ALF(-T) P AG
J 0502 QJAKEA073WJZZ JACK LGY6502-0800F P AD
J 0551 QJAKJA024WJZZ HEADPHONE CKX-035-347DBZ P AB
J 0552 QJAKLA037WJQZ JACK RCA-639HA-00A-09 P AE
J 2701 QJAKJ0101SEZZ JACK MINIATURE PHONE MORNING STAR P AB
J 9501 QJAKZA105WJQZQ JACK GCR15-N3-080A100 TRAY P AF
J 9551 QSOCZA276WJQZ SOCKET USB DOUBLE UAR64 P AE
J 9552 QSOCZA205WJQZ SOCKET UAR27-4K5C0L P AC
P 2701 QPLGNA160WJZZY CONECTOR SM04B-PASS-TBT(LF) P AD
MISCELLANEOUS PARTS
TRANSFORMER
REF No. PARTS DESCRIPTION *
PRICE
CODE
P 2702 QPLGNA158WJZZY CONECTOR SM02B-PASS-TBT (LF)(SN) P AC
P 3401 QPLGNB077WJZZY CONECTOR A1251WRO-8PS-5E JWT P AC
P 9601 QPLGN0186FJZZY CONECTOR S14B-PH-SM4-TB P AE
SC 0501 QSOCNA229WJZZ CONECTOR DHR20-151F200/H-DBR10-A0020D P AE
SC 0552 QSOCZA161WJZZ SCART RGB-11H P --
SC 1501 QSOCZA175WJZZY CONECTOR HDMI A111924-A-15-R P AE
SC 1502 QSOCZA264WJQZY CONNECTOR HDMI CSS5019-0731E P AH
SC 1503 QSOCZA264WJQZY CONNECTOR HDMI CSS5019-0731E P AH
SC 1504 QSOCZA264WJQZY CONNECTOR HDMI CSS5019-0731E P AH
SC 2601 QCNCWA995WJZZY CONECTOR LVDS 51 PINS P-TWO 187059-51221 P AF
SC 2603 QCNCWB015WJZZY cONECTOR LVDS 41 PINS P-TWO 187060-41221 P AE
SC 4401 QCNCMA340WJSA C.I.CARD SLOT ICMG68H-DS111NF(LF)(SN)JST P AK
