Sharp LC-40LE730E Service Manual

87
LC-40LE730
LC-46LE730
REF No. PARTS DESCRIPTION *
PRICE
CODE
REF No. PARTS DESCRIPTION *
PRICE
CODE
1 CCABAC769WJ01 KS-CAB-A LC46LE63*E P BD
2 CDAI-A805WJ01 KS-STAND LC46LE730E P BE
3 DUNTKF915FM02 ADJUST MAIN UNIT LE730 P CC
4 GCABAC769WJ1A FRONT CABINET P BD
5 GCABBB994WJ1A REAR CABINET P BN
6 GCOVAE259WJ1A AC HOLDER BRACKET POWER SWITCH P --
7 LANGKD343WJFW VESA BRACKET P AK
8 LANGKD369WJFW PANEL BRACKET HOLDER BOTTOM P BC
9 LANGKD373WJFW PANEL BRACKET HOLDER TOP P --
10 LANGKD375WJFW STAND BRACKET P --
11 LANGKD378WJFW TERMINAL COVER BOTTOM P AH
12 LANGKD405WJFW TERMINAL COVER SIDE P --
13 LHLDWA048WJKZ BRIDA CABLE P AA
14 LHLDWA303WJKA WIRE HOLDER P AC
15 LX-BZA425WJF7 SCREW WASHER M4x 8 mm. (Silver) P AA
16 PZETKA640WJZZ INSULATION SHEET FOR CONTROLLER PWB P --
17 PZETKA645WJKZ INSULATION SHEET POWER P AM
18 QCNW-M004WJQZ CABLE (PD) P AK
19 QCNW-M365WJQZ CABLE (LV) 51 PINS P AR
20 QCNW-M367WJQZ CABLE (LW) 41 PINS P AQ
21 R1LK460D3LB33P 46" LCD MODULE LK460D3LB33P P DQ
22 RCORFA061WJZZ FERRITE CORE/CS-FPC E04FG460812-T P --
! 23 RDENCA440WJQZ POWER WITH LED DRIVER 40" LE730 P BN
24 RSP-ZA549WJZZ SPEAKER 6 OHM 12W FULL RANGE P BA
25 RSP-ZA550WJZZ SPEAKER 2x4 OHM 5W TWEETER P AU
26 RUNTKA880WJPA2 CONTROL BUTTON UNIT LE730E BLACK P BC
27 TLABNC117WJZZ ETIQUETA MODELO 3M 7291 ADHESIVO AP-360 P AA
28 TLABZC453WJZZ PANEL LABEL P AA
29 TLABZC950WJZZ POP LABEL P --
30 TLABZD041WJZZ CE ENERGY LABEL P AH
31 XBPS730P06WS0 SCREW PAN ST ZN M3x6 P AA
32 XEPS730P08WS0 SCREW PAN ST ZN 3x8 P AA
33 XEPS730P12WS0 SCREW PAN ST ZN 3x12 P AA
34 QACCKA058WJPZ AC CORD LE730 P AQ
35
RUNTK4593TPZV LCD CONTROLER UNIT P BQ
36 LX-BZA429WJF8 STAND SCREW M4x10 BK (CSAKAA186WJ01) P --
46" CABINET AND MECHANICAL PART LISTING
REF No. PARTS DESCRIPTION *
PRICE
CODE
1 CCABAC762WJ01 KS-CAB-A LC40LE63*E/730E P BA
2 CDAI-A804WJ01 KS-STAND LC40LE730E P BE
3 TLABZC453WJZZ PANEL LABEL P AA
4 DUNTKF915FM02 ADJUST MAIN UNIT LE730 P CC
5 GCABAC762WJ1A FRONT CABINET P --
6 GCABBB993WJ1A REAR CABINET P BH
7 GCOVAE259WJ1A AC HOLDER BRACKET POWER SWITCH P --
8 LANGKD343WJFW VESA BRACKET P AK
9 LANGKD368WJFW PANEL BRACKET HOLDER (TOP AND SIDE) P BB
10 LANGKD369WJFW PANEL BRACKET HOLDER BOTTOM P BC
11 LANGKD370WJFW STAND BRACKET P BG
12 LANGKD378WJFW TERMINAL COVER BOTTOM P AH
13 LANGKD379WJFW TERMINAL COVER SIDE P AH
14 LHLDWA048WJKZ BRIDA CABLE P AA
15 LHLDWA303WJKA WIRE HOLDER P AC
16 LHLDZA929WJZZ HOLDER P AE
17 PZETKA640WJZZ INSULATION SHEET FOR CONTROLLER PWB P AG
18 PZETKA641WJZZ INSULATION SHEET FOR PANEL P AF
19 PZETKA645WJKZ INSULATION SHEET POWER P AM
20 QCNW-M004WJQZ CABLE (PD) P AK
21 QCNW-M251WJQZ CABLE (LV) 51PINS P AQ
22 QCNW-M252WJQZ CABLE (LW) 41PINS P AQ
23 R1LK400D3LB43P 40" LCD MODULE LK400D3LB43P P DG
24 RCORFA061WJZZ FERRITE CORE/CS-FPC E04FG460812-T P --
! 25 RDENCA440WJQZ POWER WITH LED DRIVER 40" LE730 P BN
26 RSP-ZA549WJZZ SPEAKER 6 OHM 12W FULL RANGE P BA
27 RSP-ZA550WJZZ SPEAKER 2x4 OHM 5W TWEETER P AU
28 RUNTKA880WJPA2 CONTROL BUTTON UNIT LE730E BLACK P BC
29 TLABNC117WJZZ ETIQUETA MODELO 3M 7291 ADHESIVO AP-360 P AA
30 TLABZC949WJZZ CE ENERGY LABEL P AH
31 TLABZC950WJZZ POP LABEL P --
32 XBPS730P06000 SCREW PAN ST ZN M3x6 P AA
33 XEPS730P08WS0 SCREW PAN ST ZN 3x8 P AA
34 XEPS730P12WS0 SCREW PAN ST ZN 3x12 P AA
35 QACCKA058WJPZ AC CORD LE730 P AQ
36
RUNTK4593TPZU LCD CONTROLER UNIT P BQ
37 LX-BZA429WJF8 STAND SCREW M4x10 BK (CSAKAA186WJ01) P --
40" CABINET AND MECHANICAL PART LISTING
