LC-40/46/52/60LE810UN (1st Edition)
4 – 2
2. Removing of Speaker-L/R.
1. Remove the 1 lock screw and detach the Stand cover .
2. Disconnect SP wire.
3. Detach the Speaker-L , Speaker-R .
MAIN Unit
2 Stand Cover
[SP]
1
4Speaker-R 3 Speaker-L
[SP]
