PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-40/46/52/60LE810UN (1st Edition)
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] CABINET AND MECHANICAL
PARTS (LC-40LE810UN)
[4] CABINET AND MECHANICAL
PARTS (LC-46LE810UN)
[5] CABINET AND MECHANICAL
PARTS (LC-52LE810UN)
[6] CABINET AND MECHANICAL
PARTS (LC-60LE810UN)
[7] SUPPLIED ACCESSORIES
[8] PACKING PARTS (LC-40LE810UN)
(NOT REPLACEMENT ITEM)
[9] PACKING PARTS (LC-46LE810UN)
(NOT REPLACEMENT ITEM)
[10] PACKING PARTS (LC-52LE810UN)
(NOT REPLACEMENT ITEM)
[11] PACKING PARTS (LC-60LE810UN)
(NOT REPLACEMENT ITEM)
[12] SERVICE JIGS
(USE FOR SERVICING)
CONTENTS
No. S30E840LE810U
LCD COLOR TELEVISION
LC-40LE810UN
LC-46LE810UN
LC-52LE810UN
LC-60LE810UN
MODELS
