LC-40/46/52/60LE810UN (1st Edition)
5 – 4
3. Entering and exiting the adjustment process mode
1) Before entering the adjustment process mode, the AV position RESET in the video adjustment menu.
2) At the state TV is turned on, touch the power key for 5seconds.
NOTE: Picture will disappear when you touch the power key, but keep touching the power key.
3) When the center icon LED blinks, release your finger from the power key.
4) Next, touch the power key with “VOL (-)” and “INPUT” keys at the same time.
TV will turn on and the letter “<K>” appears on the screen.
5) Next, touch the “VOL (—)” and “CH ( )” keys at the same time.
6) When the center icon LED turns on, release your finger form the keys.
(The “VOL (—)” and “CH ( )” keys should be pressed and held until the display appears.)
Multiple lines of blue characters appearing on the display indicate that the unit is now in the adjustment process mode.
When you fail to enter the adjustment process mode (the display is the same as normal startup), retry the procedure.
7) To exit the adjustment process mode after the adjustment is done, unplug the AC cord from the outlet to make a forced shutdown. (When the
power was turned off with the remote controller, once unplug the AC cord and plug it again. In this case, wait 10 seconds or so before plugging.)
CAUTION: Use due care in handling the information described here lest your users should know how to enter the adjustment process mode. If the
settings are tampered in this mode, unrecoverable system damage may result.
4. Remote controller key operation and description of display in adjustment process mode
1) Key operation
*Input mode is switched automatically when relevant adjustment is started so far as the necessary input signal is available.
2) Description of display
Remote controller key Main unit key Function
CH ( / )
CH ( / )
Moving an item (line) by one (UP/DOWN)
VOL (+/–) VOL (+/–) Changing a selected item setting (+1/ –1)
Cursor (UP/DOWN) ————— Turing a page (PREVIOUS/NEXT)
Cursor (LEFT/RIGHT) ————— Changing a selected line setting (+10/ –10)
INPUT ————— Input switching (toggle switching)
ENTER ————— Executing a function
(2) Current selected input
(3) Current color system
(1) Current page/
(4) Destination
(5) LCD Panel size/Speaker type
Total pages
1/24 INPUT5 AUTO USA 40_UNDER
MAIN Version
1.09 (U 2009/07/07 1A)
BOOT Version
HLNI 100
Monitor/Monitor BOOT Version
1.02/1.00
LCD Con Version
LED TCON Version
0900626000T0001
16
EQ DATA CHECKSUM
ROM
(7) Parameters
TEMPERATURE
7B
LAMP ERROR
0
MONITOR ERR CAUSE
0
NORMAL STANDBY CAUSE
0
ERROR STANDBY CAUSE
1) 0 2) 0 3) 0
0H 0M 0H 0M 0H 0M
4) 0 5) 0
0H 0M 0H 0M
(6) Adjustment
process menu
header
To Next Page
