LC-40/46/52/60LE810UN (1st Edition)
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[3] CABINET AND MECHANICAL PARTS (LC-40LE810UN)
1 CCABAC527WJ31 BS N X Front Cabinet Ass'y
1-2 HDECQB442WJ3A AA N X R/C Decoration Cover
2 CCABBB693WE01 BL N X Rear Cabinet Ass'y
2-1 GCABBB693WJSA BF N X Rear Cabinet
2-2 HiNDPD877WJSA AF N X Terminal Label S
2-3 HiNDPD700WJSA AD N X Terminal Label B
2-4 PSPAHC152WJ3Z AA N X Spacer
2-5 PSPAZC461WJZZ AC N X Spacer A
2-6 PZETKA545WJKZ AX N X Insulator
2-9 PSPAHC159WJZZ AA N X 300x10x0.5 Himeron
2-10 PSPAHC160WJZZ AB N X 170x10x0.5 Himeron
2-11 PSPAHC166WJZZ AB N X 445x8x0.5 Himeron, x2
2-12 PSPAHC167WJZZ AB N X 555x8x0.5 Himeron, x2
2-13 PSPAHC168WJZZ AB N X 565x8x0.5 Himeron, x2
!
3 QACCDA074WJPZ AG N X AC Cord
4 LHLDKA011WJKZ AB N X AC Cord Band
5 GCOVAD699WJ3A AC N X AC Cord Cover
6 GCOVAD696WJ3A AE N X Stand Cover
7 LANGKC695WJFW AD N X LCD Fixing Metal Angle B-R
8 HiNDPD718WJSA AB N X Model Label
9 LANGKC689WJM1 AE N X Vesa Angle, x2
10 LANGKC694WJFW AD N X LCD Fixing Metal Angle B-L
11 LANGKC696WJFW AD N X LCD Fixing Metal Angle T-L
12 CANGKC697WJ01 N X LCD Fixing Metal Angle T-R Ass'y
12-1 LANGKC697WJFW AD N X LCD Fixing Metal Angle T-R
12-2 PSPAHC165WJZZ AA N X Himeron
13 LHLDWA175WJUZ AC J Holder, x3
14 LHLDWA298WJKA AD N J Holder, x5
15 PZETKA544WJKZ AV N X Insulator
16 CANGKC699WJ31 AR N X Stand Angle Ass'y
16-1 LANGKC699WJFW AQ N X Stand Angle
16-2 Not available - N X Spacer, x2
17 LHLDZA587WJKZ AC J Holder, x6
18 GCOVAD734WJ00 AF N X Terminal Cover S
19 GCOVAD735WJ00 AE N X Terminal Cover B
20 NSFTZA362WJFW AA N X Shaft, x4
21 RSP-ZA458WJZZ AX N X Speaker (Sub Woofer)
22 QCNW-K548WJQZ AE N X Connecting Cord (PD:POW-MAIN)
23 QCNW-K550WJQZ AD N X Connecting Cord (PL:POW-LCD_CTL)
24 QCNW-K552WJQZ AE N X Connecting Cord (LB:POW-MAIN)
25 QCNW-K553WJQZ AF N X Connecting Cord (SB:MAIN-WOOFER)
26 QCNW-K576WJQZ AP N X Connecting Cord (LW:MAIN-LCD_CTL)
27 XBPS730P06WS0 AA J Screw, x37 (for Chassis, PWB)
28 LX-BZA364WJF7 AA N X Screw, x4 (for Sub Woofer)
29 QCNW-K551WJQZ AQ N X Connecting Cord (RA:MAN-EN/KY/RC)
30 QCNW-K554WJQZ AG N X Connecting Cord (SP:MAN-SP(L/R))
31 RSP-ZA456WJZZ AU N X Speaker, x2 (L/R)
32 XBPS730P10WS0 AA J
Screw, x3 (for LCD)
33 LX-BZA170WJF9 AA N X Screw, x4
34 XBPS830P08JS0 AB J Screw, x13 (for Rear Cabinet)
35 XBPS830P14JS0 AA N X Screw (for Terminal)
36 XEBS940P10000 AB J Screw, x4 (for Speaker)
37 TLABNB037WJZZ AB N X Serial Label (Back)
38 TLABNC391WJZZ - N X Serial Label (Side)
40 PSPAGA889WJKZ AD N X Spacer Coner-Top, x2
41 PSPAGA891WJKZ AC N X Spacer Coner-Bottm, x2
42 PZETKA562WJKZ AC N X AC Barrier
43 CDAi-A653WJ01 BE N X Stand Base Ass'y
44 CANGKC707WJ01 AT N X Support Ass'y
45 CX-BZA363WJ01 AD N X Stand Screw Ass'y
45-3 XBBS840P08000 AA N X Screw
