Sharp MX-3111U Service Manual

MX-3610N SIMULATION 5 – 13
Saddle stitch finisher (MX-FN10)
E STAPLE
BOTH
Stapling position
adjustment (center
position of two
positions binding)
68 - 132 100 When the staple off-center is
shifted, perform the
adjustment.
Staple
position
(Stapler stop
position)
(F/R
direction)
When the adjustment value is
increased, the staple position is
shifted to the rear side.
When the adjustment value is
decreased, the staple position is
shifted to the front side.
0.155mm
F STAPLE
PITCH
Stapling position
adjustment (staple
pitch of two
positions binding)
68 - 132 100 When it is required to change
the staple interval, perform
the adjustment.
Staple
position
(Stapler stop
position)
(F/R
direction)
When the adjustment value is
increased, the staple interval is
increased.
When the adjustment value is
decreased, the staple interval is
decreased.
0.155mm
G PUNCH
CENTER
Punch center
positioning sensor
37 - 63 50 When the punch off-center is
shifted, perform the
adjustment.
Punch
position
(F/R
direction)
When the adjustment value is
decreased, the punch position is
shifted to the front side.
When the adjustment value is
increased, the punch position is
shifted to the rear side.
0.1441mm
H PUNCH
HOLE
Punch hole
adjustment (paper
transport direction)
42 - 58 50 When the punch hole position
is shifted in the transport
direction, perform the
adjustment.
Punch
position
(Paper
transport
direction)
When the adjustment value is
increased, the punch position is
shifted to the paper lead edge side.
When the adjustment value is
decreased, the punch position is
shifted to the paper rear edge side.
0.2584mm
Item/Display Content
Setting
range
Default
value
Purpose (Case where the
adjustment is required)
Change when the adjustment value is
increased or decreased
Change
when the
adjustment
value is
changed by 1
Item/Display Content
Setting
range
Default
value
Purpose
(Case where the
adjustment is
required)
Change when the adjustment value is increased
or decreased
Change when
the adjustment
value is
changed by 1
ASADDLE
POSITION
Saddle stitch
position
adjustment
25 - 75 50 The adjustment is
executed when the
saddle staple
position is shifted.
Saddle paper lead
edge striking plate
stop position (Up-
down direction)
When the adjustment value is
increased, the stapling
position is shifted to the lead
edge of transported paper.
When the adjustment value is
decreased, the stapling
position is shifted to the rear
edge of transported paper.
0.2mm
B FOLDING
POSITION
Saddle folding
position
adjustment
25 - 75 50 The adjustment is
executed when the
saddle folding
position is shifted.
Saddle paper lead
edge striking plate
stop position (Up-
down direction)
When the adjustment value is
increased, the folding position
is shifted to the lead edge of
transported paper.
When the adjustment value is
decreased, the folding
position is shifted to the rear
edge of transported paper.
0.2mm
C FRONT
ADJUST
Alignment position
adjustment (front)
35 - 65 50 When the paper
alignment capability
in the stacker
section is improper,
the paper alignment
width is adjusted.
F side paper
alignment plate stop
position
(F/R direction)
When the adjustment value is
increased, the alignment
position is shifted to the
center.
When the adjustment value is
decreased, the alignment
position is shifted to the
outside.
0.2mm
D REAR
ADJUST
Alignment position
adjustment (Rear)
35 - 65 50 R side paper
alignment plate stop
position
(F/R direction)
When the adjustment value is
increased, the alignment
position is shifted to the
center.
When the adjustment value is
decreased, the alignment
position is shifted to the
outside.
0.2mm
E STAPLE REAR Stapling position
adjustment (Rear,
one position)
25 - 75 50 When the stapling
position on the R
side is shifted, the
adjustment is
executed.
Stapling position
(stapler stop
position)
(F/R direction)
When the adjustment value is
increased, the distance
between the stapling position
and the paper edge becomes
longer.
When the adjustment value is
decreased, the distance
between the stapling position
and the paper edge becomes
shorter.
0.2mm
