Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and the detectors in the finisher and
the control circuit.
Section
Finisher
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The code names of the sensors and the detectors which are active
are highlighted.
<Inner finisher>
<Saddle stitch finisher>
<4K finisher>
FED Entry port paper detection (Status detection "1")
FBED Tray paper detection
FULD Tray upper limit detection
FMLLD Tray intermediate lower limit detection
FLLD Tray lower limit detection
FSLD1 Paper surface detection 1
FSLD2 Paper surface detection 2
FRLD Roller up/down detection
FBRD Belt separation detection
FFJHPD Alignment HP detection front
FRJHPD Alignment HP detection rear
FJPD Alignment guide position detection
FSTPD Staple tray paper detection
FSHPD Staple drive HP detection
FSTHPD Staple shift HP detection
FSD Staple empty detection
FSTD Staple lead edge position detection
FDSW Door open detection
FFANLK Fan motor lock detection
FPRPD Punch rear position detection (Status detection "1")
FPUC Punch unit connection detection
FPHPD Punch HP detection
FPSHPD Punch side resist HP detection
FPPD1 Punch paper surface detection 1
FPPD2 Punch paper surface detection 2
FPPD3 Punch paper surface detection 3
FPPD4 Punch paper surface detection 4
FPPD5 Punch paper surface detection 5
FPPD6 Punch paper surface detection 6
FPDD Punch dust detection
FPPEND Punch paper rear edge detection
FPDES1 Punch destination detection 1
FPDES2 Punch destination detection 2
㩷
㩷
㩷
㩷
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
63)287387&+(&.


6350B)
63
63)0
50B5 63)&
655& 6*6
67036
(;(&87(



PDPPD1 Paper pass paper transport detector 1
PDPPD2 Paper pass paper transport detector 2
PDCS Paper pass cover Open/Close sensor
FPPD1 Paper delivery detector 1
FPAPHS_F Paper alignment plate home position sensor F
FPAPHS_R Paper alignment plate home position sensor R
FATPD Paper alignment tray paper detector
FGHPS Gripper home position sensor
FDTPD Delivery tray paper detector
FPLD Paper surface detector
FPPD2 Paper transport detector 2
FSPHS Saddle plate home position sensor
FSTPD Saddle exit tray paper detector
FSMRS Saddle motor rotation sensor
FTULD Tray upper limit detector
FTLLD Tray lower limit detector
FTLMRS Tray lift motor rotation sensor
FSHS Staple home position sensor
FSSHPS Stapler shift home position sensor
FSED Staple empty detector
FSLS Staple lead edge sensor
FTPS Tray position sensor
FCD1 Cover detector 1
FCD2 Cover detector 2
FSSW1 Safety switch 1
FCD Finisher connection detector
FSSSW1 Staple safety switch
FFL Fan lock signal
FDRHS Delivery roller home position sensor
FPPD3 Paper transport detector 3
FSATPD Saddle paper alignment tray paper detector
FSSSW2 Stapler safety switch 2
FPHHD Paper hold home position sensor
FSAPHS Saddle alignment plate home position sensor
FSPGHS Saddle paper guide home position sensor
FSRHS Saddle roller home position sensor
FPDD Delivery detector
FSSHS Saddle staple home position sensor
FSSES Saddle staple sensor
FSSCS Saddle staple cover sensor
FSSSHS Finisher saddle stapler shift home position sensor
FPMRS Punch motor rotation sensor
FPD Punch unit detection (connector)
FPCHPS Punch home position sensor
FPDFS Punch dust sensor
FPHPS Punch unit home position sensor
FPTS Punch timing sensor
FPES1 Punch paper edge sensor 1
FPES2 Punch paper edge sensor 2
FPES3 Punch paper edge sensor 3
FPES4 Punch paper edge sensor 4
FPPS Punch paper position sensor
FJPID Interface transport unit entry port detection
FJPOD Interface transport unit exit port detection
FJPDD Interface transport unit cover detection
FED Entry port paper detection
FAED1 Tray 1 area detection 1
FAED2 Tray 1 area detection 2
FAED3 Tray 1 area detection 3
FFJHPD Alignment plate HP detection front
FRJHPD Alignment plate HP detection rear
FBED1 Tray 1 paper detection
FBED2 Tray 2 paper detection
FCCD Tray approach detection
FSLD1 Tray 1 paper surface detection
FPDD1 Discharged paper detection
FSLD2 Tray 2 paper surface detection
FASHPD Rear edge assist HP detection
