Sharp MX-4101N

MX-5001N MAINTENANCE 8 – 34
H. Paper feed section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean S: Replace U: Adjust ✩: Lubricate
No. Part name
When
calling
150
k
300
k
450
k
600
k
750
k
900
k
1050
k
1200
k
1350
k
1500
k
1650
k
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
1 Pickup roller Mechanical
parts
✕ {{{{{{ {{{{{Replace as needed.
Reference: About 100k
2 Paper feed roller ✕ {{{{{{ {{{{{
3 Separation roller ✕ {{{{{{ {{{{{
4 Torque limiter ✕ ✕✕✕✕✕✕✕✕✕✕✕
5 Transport rollers ✕ {{{{{{ {{{{{
6Sensors ✕ ✕✕✕✕✕✕✕✕✕✕✕
7 Transport paper
guides
{ {{{{{{ {{{{{
1
2
3
5
6
6
3
5
5
6
4
1
6
6
4
2
6
3
5
2
6
4
1
6
6
6
6
6
5
