MX-M350/M450 N/U CONSUMABLE PARTS 4 - 2
2. Maintenance parts list
A. USA/Canada
B. Europe/Australia/New Zealand/Taiwan
Note: The other maintenance parts which are not listed above are registered as service parts.
No. Item Content Life Model name Remarks
1 200K Maintenance kit Cleaner blade x 1 200K AR-455KA1 *1:Screen grid, charging plate, MC
cleaner unit are included.
Drum separation pawl x 4
MC unit *1 x 1
Toner receiving seal x 1
Side malt F x 1
Side malt R x 1
Transfer roller x 1
Discharge plate x 1
Paper dust removing unit x 1
DV blade x 1
DV side seal F x 1
DV side seal R x 1
2 Upper heat roller kit Upper heat roller x 1 200K AR-455UH
Fusing separation pawl (Upper) x 4
3 Lower heat roller kit Lower heat roller x 1 200K AR-455LH
Fusing separation pawl (Lower) x 2
4 Cleaner blade Cleaner blade x 10 200K (x 10) AR-455CB AR-455CB = (AR-455BL) x 10
5 Cleaning roller kit Cleaning roller x 10 200K (x 10) AR-455CR AR-455CR = (AR-455RC) x 10
Bearing x 20
6 Staple cartridge Staple cartridge x 3 3000 times x 3 AR-SC1 Cartridge for AR-FN4
Common with cartridge for AR-FN6
7 Staple cartridge Staple cartridge x 3 5000 times x 3 AR-SC2 Cartridge for AR-FN7
No. Item Content Life Model name Remarks
1 200K PM kit Cleaner blade x 1 200K AR-451KA *1: Screen grid, charging plate, MC
cleaner unit are included.
Drum separation pawl x 4
MC unit *1 x 1
Toner receiving seal x 1
Side malt F x 1
Side malt R x 1
Transfer roller x 1
Discharger plate x 1
Paper dust removing unit x 1
DV blade x 1
DV side seal F x 1
DV side seal R x 1
Upper heat roller x 1
Fusing separation pawl (Upper) x 4
Lower heat roller x 1
Fusing separation pawl (Lower) x 2
Cleaning roller x 1
Bearing x 2
2 Staple cartridge Staple cartridge x 3 3000 times x 3 AR-SC1 Cartridge for AR-FN4
Common with cartridge for AR-FN6
3 Staple cartridge Staple cartridge x 3 5000 times x 3 AR-SC2 Common with cartridge for AR-FN7
