Sharp MX-M350

MX-M350/M450 N/U SIMULATION 9 - 80
Operation/Procedure
1) Enter the DTMF signal (1 - 9, 0, *, #) to be sent with 10-key.
2) Press [START] key.
The signal is sent in the max. send level.
When [SYSTEM SETTINGS] key is pressed during execution, the
operation is stopped.
Operation/Procedure
1) Enter the DTMF signal (1 - 9, 0, *, #) to be sent with 10-key.
2) Press [START] key.
The signal is sent in the send level set with the soft SW.
When [SYSTEM SETTINGS] key is pressed during execution, the
operation is stopped.
Operation/Procedure
1) Select YES/NO of data transfer (backup).
2) Press [START] key.
This function is valid only when the AR-MM9 is installed.
Backup contents
The other contents are not backed up.
Select 0 and press [START] key. Press [SYSTEM SETTINGS] key.
66-17
Purpose Setting
Function
(Purpose)
Used to check the dial signal (DTMF) output in the
FAX tone dial mode. Send level: Max. Used to
check the operation. (Only when FAX is installed)
Section FAX
Item Operation
Press [START] key. Press [SYSTEM SETTINGS] key.
66-18
Purpose Setting
Function
(Purpose)
Used to check the dial signal (DTMF) output in the
FAX tone dial mode. An output is sent at the send
level set by the soft switch. Used to check the
operation. (Only when FAX is installed)
Section FAX
Item Operation
SIMULATION 66-16
DIAL TEST(DTMF). SELECT 0-2, AND PRESS START.
0. EXECUTE
1. HIGH 7 (dB) 2. HIGH-LOW 7
SIMULATION 66-16
DIAL TEST(DTMF). SELECT 0-15, AND PRESS START.
1. HIGH(dB)
1
7
Press [SYSTEM SETTINGS] key
or press [START] key.
Select 1 or 2, and
press [START] key.
(When 1)
SIMULATION 66-16
DIAL TEST(DTMF). SELECT 0-15, AND PRESS START.
1. HIGH(dB)
7
(When 2)
SIMULATION 66-16
DIAL TEST(DTMF). EXECUTING···.
1. HIGH 7 (dB) 2. HIGH-LOW 7
(When 0)
SIMULATION 66-17
DTMF SIGNAL OUTPUT.(LEVEL MAX) INPUT 0-9, *, #, AND
PRESS START.
1
SIMULATION 66-17
DTMF SIGNAL OUTPUT.(LEVEL MAX) EXECUTING···.
1
Press [START] key. Press [SYSTEM SETTINGS] key.
66-19
Purpose Data transfer
Function
(Purpose)
Used to back-up the HDD data into the Flash
memory (optional FAX expansion memory: AR-
MM9). (Only when FAX is installed)
Section FAX
Item Data
1 YES Backup is executed.
2 NO Backup is not executed.
• Address book data (FAX, Mail, Address)
• One-touch dial • Item name
• FTP expansion • Fine name
• Group expansion • FAX receive select table
• Program • Internet FAX receive YES/NO
• Use index • Polling allow number
• Standard sender • Memory box
• Internet FAX sender registration • Sender name
• FAX sender registration • Soft SW
SIMULATION 66-18
DTMF SIGNAL OUTPUT.(SOFT SW.) INPUT 0-9, *, #, AND PRESS
START.
1
SIMULATION 66-18
DTMF SIGNAL OUTPUT.(SOFT SW.) EXECUTING···.
1
SIMULATION 66-19
ADDRESS DATA BACK UP. (WRITE TO FLASH ROM)
ARE YOU SURE?
1. YES
2. NO
SIMULATION 66-19
ADDRESS DATA BACK UP. (WRITE TO FLASH ROM) EXECUTING...
1
1
Press [START] key.
After completion of backup
