Sharp MX-M350

MX-M350/M450 N/U SIMULATION 9 - 84
Operation/Procedure
1) Enter the number corresponding to the check mode with 10-
key.
2) Press [START] key.
When check is completed normally, "OK" is displayed. Incase of
an error, "NG" is displayed.
When check is "repeat," the operation is continued until the result
is NG or [SYSTEM SETTINGS] key is pressed.
Operation/Procedure
1) Enter the number corresponding to the destination.
2) Press [START] key.
Operation/Procedure
1) The confirmation window is displayed. Select whether rewrit-
ing of the program into PIC installed in the FAX VOX is per-
formed or not.
NOTE: Release the write protect notch.
FAX program writing enabled (Jumpers and DIP SW
depending on the model.)
2) Press [START] key.
When reload is completed normally, "OK" is displayed. In case of
an error, "NG" is displayed.
NG cause:
• Write protect is set.
• PIC is not installed.
• Access error to PIC
Press [START] key.
After completion of reloading
66-36
Purpose Operation test/Check
Function
(Purpose)
Used to check interface between MFPC controller
and MDMC. (Check of the data line or the
command line) (Only when FAX is installed)
Section FAX
Item Operation
1MFPC ← MDMC (DATA once) Date line once only
2MFPC → MDMC (DATA once) Date line once only
3MFPC ← MDMC (DATA repeat) Data line repeat
4MFPC → MDMC (DATA repeat) Data line repeat
5MFPC ← MDMC (CMD once) Command line once only
6MFPC → MDMC (CMD once) Command line once only
7MFPC ← MDMC (CMD repeat) Command line repeat
8MFPC → MDMC (CMD repeat) Command line repeat
SIMULATION 66-35
MODEM PROGRAM RELOAD.
ARE YOU SURE?
1. YES
2. NO
1
SIMULATION 66-35
MODEM PROGRAM RELOAD. EXECITOMG···
LOADER··· xxxxx
MODEM···· xxxxx
SIMULATION 66-35
MODEM PROGRAM RELOAD.
LOADER···OK
MODEM····COMPLETE
SIMULATION 66-36
MFPC-MDMC I/F CHECK. INPUT 1-8, AND PRESS START.
1. MFPC<-MDMC(DATA once)
2. MFPC->MDMC(DATA once)
3. MFPC<-MDMC(DATA repeat)
4. MFPC->MDMC(DATA repeat)
5. MFPC<-MDMC(CMD once)
6. MFPC->MDMC(CMD once)
7. MFPC<-MDMC(CMD repeat)
8. MFPC->MDMC(CMD repeat)
1
SIMULATION 66-36
MFPC-MDMC I/F CHECK. INPUT 1-8, AND PRESS START.
EXECUTING...(OK or NG)
SIMULATION 66-36
MFPC-MDMC I/F CHECK. INPUT 1-8, AND PRESS START.
EXECUTING...
Press [START] key.
When check is "once" or
"repeat" and the result is "NG":
When check is "repeat" and
[SYSTEM SETTINGS] key ON:
66-39
Purpose Setting
Function
(Purpose)
Used to set the destination specifications. (Only
when FAX is installed)
Section FAX
Item Specifications Operation
66-42
Purpose Setting
Function
(Purpose)
PIC program rewriting (Only when FAX is
installed)
Section FAX
Item Operation
1 YES Execution
2 NO Cancel
SIMULATION 66-39
FAX DESTINATION SETUP.
SELECT 1-6, AND PRESS START
0. NO DESTINATION
1. JAPAN
2. U.S.A./CANADA
3. EUROPE
4. AUSTRALIA
5. CHINA
6. ASIA&OTHERS
1
Press [START] key.
SIMULATION 66-42
PIC PROGRAM RELOAD.
ARE YOU SURE ?
1.YES
2.NO
1
Press [START] key.
Press [START] key.
SIMULATION 66-42
PIC PROGRAM RELOAD EXECUTING
...
.
Press [ SYSTEM SETTINGS] key.
SIMULATION 66-42
PIC PROGRAM RELOAD
OK
