Sharp Notevision PG-B10S User Manual

-24
In addition to the zoom function and adjustment of projection angle using the adjustment foot, it is possible
to move the lens up and down and left and right (360°) to adjust the projection position simply by moving the
lens shift lever on the front of the projector. This is a useful function in cases such as when the screen can
not be moved.
Variable Lens Shift Feature
When moving upward or downward
Adjustable range
Adjustable range
Adjustable range
Adjustable range
Lens shift lever
Adjustable range of the lens shift lever
The adjustable range using the lens shift lever has limitations.
The image can be adjusted as shown below.
Adjustable range of
the image center
Image center
Width of the projected image × 30%
Height of the projected
image × 50%
Image center locus
Zooming axis
When moving in the left and right direction
Lens shift lever
