Sharp SF-2314 Service Manual

Purpose/kind Section
Contents
Ref. page
Main
code
Sub
code
Default
value
Description
Setting Fuser unit 26 13 0 Setting of the main motor operation mode in warming up. 8-8
43 1 185˚C Fusing temperature set value 8-8
2 0 Fusing temperature setting value in the power save mode 8-8
Process 44 1 16 Picture correction mode function setting
Counter Total counter 22 5 Used to confirm the total counter value. 8-9
20 1 Used to reset the maintenance counter. 8-9
21 1 2 Used to set the maintenance cycle. 8-9
22 1 Used to confirm the maintenance count value. 8-9
2 Used to confirm the set maintenance cycle (maintenance preset
counter).
8-9
Trouble
cancel
14 Used to cancel troubles other than self diag "U2".
After cancellation of the trouble, the simulation is also cancelled
automatically.
8-12
16 Used to cancel self diag "U2" trouble.
After cancellation of the trouble, the simulation is also cancelled
automatically.
8-12
[11] MAINTENANCE
▲ Replacement/Installation F Cleaning ✭ Lubrication
✕ Check (Clean, replace, or adjust as required.) v
Content 40K 80K 120K 160K 200K 240K
Developing Developer ▲▲▲▲▲▲
Toner supply
Seal ✕✕✕✕✕✕
Process,
peripheral
OPC drum ▲▲▲▲▲▲
Main charger, saw tooth, grid, separation
pawl
▲▲▲▲▲▲
Transfer charger wire F ▲ F ▲ F ▲
Separation plate (half etching) ▲▲▲▲▲▲
Transfer charger case F ▲ F ▲ F ▲
Fusing Fusing lower CL roller ▲▲▲▲▲▲
Fusing upper heat roller F ▲ F ▲ F ▲
Fusing bearing F ▲ F ▲ F ▲
Fusing gear F ▲ F ▲ F ▲
Fusing lower heat roller F ▲ F ▲ F ▲
Thermistor FFFFFF
Fusing upper separation pawl F ▲ F ▲ F ▲
Fusing lower separation pawl F ▲ F ▲ F ▲
Optical Mirror, lens, reflector FFFFFF
Sensors FFFFFF
Drive wire, pulley ✕✕✕✕✕✕
Mirror base rail ✭✭✭✭✭✭
Glass, OC matt FFFFFF
Transport Manual paper feed section roller FFFFFF
Cassette paper feed section roller FFFFFF
Paper transport rollers FFFFFF
Suction belt (only target destinations) Japan FFFFFF
Paper transport section paper guide FFFFFF
SPF Paper feed roller FFFFFF
Transport roller FFFFFF
Original transport guide FFFFFF
OC matt FFFFFF
Other Gears (drive sections) ✭✭✭✭✭✭
Blank lamp, discharge lamp FFFFFF
Ozone filter ✕▲✕▲✕▲
Picture quality vvvvvv
Code
No.
Operation
mode
Operation
0
Normal
mode
When the fusing temperature reaches
the specified level, the main motor stops.
1
Long
mode
The main motor keeps rotating until the
completion of the warming up.
11 – 1
