Sharp SF-2314 Service Manual

[2] PRODUCT SPECIFICATIONS
1. Basic specifications
(1) Type: Table top
(2) Copy speed
• SF-2314
Paper size Normal Enlargement Reduction
B4 11 sheets/min — —
A4 (Landscape) 14 sheets/min — —
B5 (Landscape) 14 sheets/min — —
10″ × 14″ 11 sheets/min — —
Legal 11 sheets/min — —
Letter (Landscape) 14 sheets/min — —
• SF-2414/2514
Paper size Normal Enlargement Reduction
B4 11 sheets/min 10 sheets/min 12 sheets/min
A4 (Landscape) 14 sheets/min 10 sheets/min 12 sheets/min
B5 (Landscape) 14 sheets/min 10 sheets/min 12 sheets/min
10″ × 14″ 11 sheets/min 10 sheets/min 12 sheets/min
Legal 11 sheets/min 10 sheets/min 12 sheets/min
Letter (Landscape) 14 sheets/min 10 sheets/min 12 sheets/min
Note: Copy speeds in the enlargement/reduction copy are the
same in all the rates.
(3) Warm-up time
Normal 30 sec or less (20 ˚C, 65%RH, rated
voltage)
(Preheat YES/NO) 10sec or less (Preheat mode)
Max. 30sec (auto power shut off
mode/auto off mode)
Jam recovery time 8sec (Conditions: Standard condition
after 60sec of leaving after opening
the door.)
(4) First copy time
First copy time 5.9sec (Paper feed port: No. 1 tray)
First copy time from
each paper feed port
No. 2 tray (option): 6.8sec
Manual: 5.9sec
(5) Jam recovery time: 5 sec (Condition: Jam in a section except
for the fuser section, within 6.0 sec from
door open, standard condition.)
(6) Multi copy
Max. quantity of multi copy 99 sheets
(7) Original
Max. original size B4/10 × 14″
Original reference
position
Left side, about 12mm from the rear
Detection NO
Detection size AB series
Inch series
(8) Copy magnification ratio (SF-2414/2514 only)
Fixed
ratio
AB series 3R+3E/129, 122, 115, 81, 70, 64%
Inch series 2R+2E/129, 117, 78, 64%
Zoom width 64 ∼ 129%
(9) Exposure
Exposure mode Auto/Manual/Photo
Manual steps 9 steps
(10) Void width
Normal Reduction Enlargement
Void area
Lead edge
3.0mm or less
Lead edge
3.0mm or less
Lead edge
3.0mm or less
Side (front)
3.0mm or less
Side (front)
3.0mm or less
Side (front)
3.0mm or less
Rear edge
1mm ∼ 3.0mm
Rear edge
1mm ∼ 3.0mm
Rear edge
1mm ∼ 3.0mm
loss
Lead edge
3.0mm max.
Lead edge
5.0mm max.
Lead edge
2.5mm max.
Side (front)
3.0mm max.
Side (front)
5.0mm max.
Side (front)
2.5mm max.
Rear edge
4.0mm max.
Rear edge
6.0mm max.
Rear edge
3.0mm max.
(11) Paper exit
Paper exit tray capacity 100 sheets
(12) External view
W × D × H (mm)
OC top
Common in
SF-2314/2414
500 × 502 × 295
W × D × H (mm)
SPF top
SF-2514 540 × 502 × 364
Occupying
area
W (mm) Common in
SF-2314/2414
500 + 261 (paper
exit tray) + 205
(option Multi
paper feed unit)
S (mm) 502
Weight SF-2314
about
26.8kg
SF-2414
about 27kg
SF-2514 about
30.1kg
(13) Power source
Voltage 100V, 110V, 120V, 127V, 220V, 220 ∼ 230V, 230 ∼
240V, 240V
Frequency 50/60Hz common
(14) Power consumption
Max. power consumption 1.4 kW
Average power consumption when
operating (Ref. value)
582.4 Wh
Power consumption in standby
(Ref. value)
72.5 Wh
Power consumption in pre-heating
(Ref. value)
47.7 Wh
Power consumption in auto power
shut off (Ref. value)
16.5 Wh (with SPF)
14.8 Wh (without SPF)
Auto OFF mode (Ref. value)
Dry heater connected
Dry heater not connected
9.5 Wh
0 Wh
Energy consumption efficiency 49.4 Wh
Note: Max. value when an option is installed.
2. Details of each section
(1) Paper feed
Copying size
(Max. ∼ Min.)
AB series B4 ∼ A6 (Postcard)
Inch series 10 × 14 ∼ 5 1/2 × 8 1/2
Paper feed system 1 tray + single manual feed
Paper feed capacity 250 sheets × 1
2 – 1
