Creating a Logo Image
Page / 10
Designs and specifications are subject to change without notice.
Prior to starting the Logo conversion application it is recommended that you create and format the image
data to be used by setting the attributes to be within the previously mentioned specifications.
Format Specifications:
(1) File format: *.PCX or *.BMP
(2) Size: 360 dots (w) x 130 dots (h)
(3) Color: Monochrome only (black & white)
The *.bmp or *.pcx image data can easily be modified using PC-based applications to the above
specifications as shown in the illustration below (Fig. 11);
(FIG.11)
CREATING A LOGO IMAGE
