Converting Image Data
Page / 13
Designs and specifications are subject to change without notice.
The UP-700 Logo utility also supports the conversion of image data that meets the necessary
specification previously outlined to be used with the ER02FD.exe PC utility as an alternative means of
loading a graphics logo.
1. From the Main Form using the drop down menu, select one of the following functions to be
performed (Fig. 18);
(1) Convert Logo1 when the image data is for the header
(2) Convert Logo2 when the image data is for the footer
2. Click [ OK ]
3. The LOGOCONV.exe will prompt you if you have an image file ready for conversion.
Click [Continue] if you have a file that has been prepared. (Fig. 19)
4. Navigate to the applicable folder where the image data is stored and select the image. (Fig. 20)
CONVERTING IMAGES FOR USAGE WITH THE ER02FD.EXE
(FIG.18)
(FIG.19)
(FIG.20)
