Introduction
Page / 2
Designs and specifications are subject to change without notice.
This document will help you utilize the graphics logo function of the UP-700 model ECR. This
documentation assumes that you are familiar with general PC and the Microsoft® Windows operating
system as it relates to the settings for the desk top, communications ports, etc. Please read this
introductory section carefully as it will provide helpful hints and recommendations that will make your time
more efficient and produce time saving results.
RECOMMENDED SEQUENCE FOR THE UP-700 SETUP
INTRODUCTION
1. Always install the necessary options (i.e. Optional RAM, etc.) prior to programming.
2. Start your programming sessions by executing one of the Master Reset operations.
(for detailed information about the Master Reset operations, please refer to the applicable Service Manual)
3. Recommended order for programming;
Please complete the SRV-mode and PGM-mode sections in the order outlined below:
(1) Always back up your program prior when loading the Logo Image data into an existing
customer's machine.
(2) Set the applicable SRV parameters (SRV job #912).
(the Logo image data replaces the ECR's "STAMP" image)
(3) Load the image data to be used as the Logo (header or footer)
(4) Perform a Program Reset (SRV Reset).
(5) Back up the NEW Program with the Logo Image
(6) Test system performance and reporting prior to installation.
