PREPARING THE UP-700
1. The UP-700 SIO Function Connection:
In addition to setting the graphics logo print control, the image data may be sent to the UP-700
using the SIO Function.
The Program Back up/Restore (SIO) function has been fixed to port-2 (CH #2) of the UP-700 as
shown below in (Fig. 4 and Fig. 5):
(FIG.4)
1
2
1
UP-P16DP
UP-E13MR
In-Line cable
RS232 devices
ER-A6HS1
and
RS232 devices
When using the SIO
function, the connection
for the cable is port-2
(CH-2)
(FIG.5)
