Sharp UX-108 Service Manual

UX-108U/178U/188U
FO-375U
NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
– 2 –
[1] Cabinet etc.
1 LFRM-2184XHZZ AP N C Head frame
2 MSPRC2949XHZZ AC N C Head spring A
3 MSPRC2950XHZZ AC N C Pinch roller pressing spring
4 NROLP2334XHZA AC N C Pinch roller
5 NSFTZ2281XHZZ AD N C Pinch roller shaft
6 PGIDP2497XHZZ AC N C Head support,left
7 PGIDP2498XHZZ AC N C Head support,right
8 PSHEZ3324XHZZ AD N C Head sheet
9 QCNW-4748XHZZ AP N C Head cable
10 QCNW-4817XHZZ AE N C Head earth cable
11 RHEDZ2054XHZZ BP N B Thermal head
12 DCEKP370BXH01 BL N E Operation panel unit [108U/178U]
DCEKP370BXH05 BF N E Operation panel unit [188U]
DCEKP370BHX04 BF N E Operation panel unit [375U]
13 LBNDJ2006XHZZ AA C Band(GT-100M)
14 LSTPF2049XHZZ AD N C Stopper plate
15 QCNW-4816XHZZ AL N C Panel cable
17 CCNW-4745XH01 AL N C Speaker ass’y
18 GCABB2298XHZA AT N D Lower cabinet [108U/178U]
GCABB2298XHZC AT N D Lower cabinet [188U]
GCABB2298XHZB AT N D Lower cabinet [375U]
19 MLEVP2263XHZZ AC N C Paper sensor lever [178U/188U/375U]
20 MSPRD2947XHZZ AC N C Paper sensor lever spring [178U/188U/375U]
21 DCEKL366BXH01 BE N E TEL/Liu PWB unit
22 GCASP2099XHZZ AN N C PWB case,top
23 GCASP2100XHZZ AN N C PWB case,bottom
24 QACCZ2012XHZZ AT N B AC cord ass’y
!
25 RDENT2116XHZZ BN N E Power supply PWB unit
26 GDAI-2078XHZA AH N C Handset cover [108U/178U]
GDAI-2078XHZC AH N C Handset cover [188U]
GDAI-2078XHZB AH N C Handset cover [375U]
27 MLEVP2261XHZZ AD N C Hook switch lever
28 LFRM-2185XHZZ AH N C Scanner fram
29 MSPRC2948XHZZ AC N C CIS spring
30 NGERH2379XHZZ AC N C Idler gear,25Z
31 NGERH2380XHZZ AC N C Reduction gear,17/36Z
32 NGERH2392XHZZ AC N C Reduction gear,17/21Z
33 NROLR2375XHZZ AL N C Feed roller
34 NSFTZ2273XHZZ AF N C Feed roller shaft
35 PGIDP2513XHZZ AH N C CIS support,left [108U]
PGIDP2499XHZZ AD N C CIS support,left [178U/188U/375U]
36 PGIDP2514XHZZ AH N C CIS support,right [108U]
PGIDP2500XHZZ AD N C CIS support,right [178U/188U/375U]
37 PGIDP2505XHZZ AF N C Document guide lower
38 QCNW-4814XHZZ AG N C CIS cable [108U]
QCNW-4747XHZZ AH N C CIS cable [178U/188U/375U]
39 RUNTZ2021SCZZ BF N B CIS unit [108U]
RUNTZ2020SCZZ BF N B CIS unit [178U/188U/375U]
40 MLEVP2262XHZZ AD N C Paper sensor lever
41 MSPRC2989XHZZ AC N C Paper sensor lever spring
42 PGIDP2496XHZZ AD N C Paper support guide
43 DCEKC587JXHZZ BV N E Control PWB unit(Within ROM) [108U]
DCEKC586JXHZZ BZ N E Control PWB unit(Within ROM) [178U/188U/375U]
44 LBSHP2092XHZZ AC N C Platen bearing
45 MARMP2019XHZZ AC N C Cutter arm [178U/188U/375U]
46 MSPRC2945XHZZ AC N C Anti curl spring
47 NGERH2382XHZZ AC N C Platen gear
48 NROLP2332XHZZ AD C PO pinch roller
49 NROLR2376XHZZ AX N C Platen roller
50 NSFTZ2274XHZZ AK N C Anti curl shaft
51 PCUT-2037SCZZ AT N C Cutter [178U/188U/375U]
52 PGIDP2506XHZZ AE N C Cutter guide [178U/188U/375U]
53 PGIDP2507XHZZ AF N C Cutter cover [178U/188U/375U]
54 GLEGG2068XHZZ AC N C Rubber leg
55 PSHEZ3325XHZZ AD N C Jack sheet
56 PGIDP2503XHZZ AH N C Paper guide upper [108U]
57 PSHEZ3362XHZZ AD N C Guide sheet
58 MSPRC3005XHZZ AC N C Head spring B
!
59 RCORF2103XHZZ AF B Core
!
60 RCORF2064XHZZ AF B Core

Sharp UX-108 Specifications

General

Brand	Sharp
Model	UX-108
Category	Fax Machine
Language	English
