Sharp UX-108 Service Manual

UX-108U/178U/188U
FO-375U
NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
– 4 –
[2] Upper cabinet
1 GCABA2297XHZA AT N D Upper cabinet [108U/178U]
GCABA2297XHZC AT N D Upper cabinet [188U]
GCABA2297XHZB AT N D Upper cabinet [375U]
2 JBTN-2216XHZA AF N C 12 key [108U/178U]
JBTN-2216XHZC AF N C 12 key [188U]
JBTN-2216XHZB AF N C 12 key [375U]
3 JBTN-2217XHZA AD N C Direct key [108U/178U]
JBTN-2217XHZC AE N C Direct key [188U]
JBTN-2217XHZB AE N C Direct key [375U]
4 JBTN-2218XHZZ AE N C Start key
5 JBTN-2219XHZZ AD N C Stop key
6 LPLTP2909XHZA AE N C Document tray [108U/178U]
LPLTP2909XHZC AE N C Document tray [188U]
LPLTP2909XHZB AE N C Document tray [375U]
7 MSPRC2954XHZZ AC N C Hopper spring
8 NGERP2318XHZZ AD C Pinion gear
9 PGIDP2501XHZA AE N C Hopper guide,left [108U]
PGIDP2501XHZC AE N C Hopper guide,left [188U]
PGIDP2501XHZB AE N C Hopper guide,left [375U]
10 PGIDP2502XHZA AE N C Hopper guide,right [108U]
PGIDP2502XHZC AE N C Hopper guide,right [188U]
PGIDP2502XHZB AE N C Hopper guide,right [375U]
11 HPNLH2383XHZB AK N D Decoration panel [108U]
HPNLH2383XHZA AK N D Decoration panel [178U]
HPNLH2383XHZD AK N D Decoration panel [188U]
HPNLH2383XHZC AD N D Decoration panel [375U]
12 QCNW-4816XHZZ AL N C Panel cable
13 DCEKP367BXH01 BH N E Operation panel PWB unit
14 LBNDJ2006XHZZ AA C Band
(Unit)
901 DCEKP370BXH01 BL N E Operation panel unit [108U/178U]
DCEKP370BXH05 BF N E Operation panel unit [188U]
DCEKP370BXH04 BF N E Operation panel unit [375U]
[3] Document guide upper
1 LBSHP2093XHZZ AC N C Bearing
2 LPLTG2911XHZZ AE N C Separator rubber
3 LPLTP2908XHZZ AE N C Separator plate
4 MLEVP2264XHZZ AD N C Panel lock lever
5 MLEVP2265XHZZ AD N C Document sensor lever
6 MSPRD2953XHZZ AC N C Document sensor lever spring
7 MSPRP2944XHZZ AC N C Paper feed spring
8 MSPRT2951XHZZ AC N C Separate spring
9 MSPRT2951XHZZ AC N C Panel lock lever spring
10 NGERH2383XHZZ AC N C Idler gear,20
11 NGERH2402XHZZ AC N C CIS gear,29Z
12 NROLR2372XHZZ AL N C CIS roller A ass’y
13 NROLR2373XHZZ AL N C CIS roller B ass’y
14 NROLR2374XHZZ AP N C Transfer roller
15 PGIDP2504XHZZ AF N C Document guide upper
16 PSHEZ3355XHZZ AD N C Rear sheet
