UX-108U/178U/188U
FO-375U
NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
– 9 –
[7] Control PWB unit
81 QCNCM7014SC0G AB C Connector(7pin) [CNCIS]
82 QCNCM2442SC0B AB C Connector(2pin) [CNCSW]
83 QCNCM7014SC0B AD C Connector(2pin) [CNCUT1][178U/188U/375U]
84 QCNCW2500SC1B AF C Connector(12pin) [CNLIUA]
85 QCNCM7014SC0F AB C Connector(6pin) [CNMT]
86 QCNCM7014SC1E AC C Connector(15pin) [CNPN]
87 QCNCW2500SC1J AD N C Connector(10pin) [CNPW]
88 QCNCM2401SC0B AA C Connector(2pin) [CNSP]
89 QCNCM7014SC1F AD C Connector(16pin) [CNTH]
90 VHERD22FB3/-1 AC B Diode(RD22FB3) [D1]
92 VHD1SS355//-1 AB B Diode(1SS355) [D100]
93 VHDRB705D//-1 AD B Diode(RB705D) [D101]
!
94 VHVICPS07//-1 AA B Varistor(ICP-S07) [FU100]
95 VHIMC34119DR2 AH N B IC(MC34119DR2) [IC1]
96 VHIR96XFC3CID BR N B IC(R96DFXL-CID)[Within IC2 and IC3 pair] [IC2]
97 VHIR96XFC3CID BR N B IC(XFC3)[Within IC2 and IC3 pair) [IC3]
98 VHIHCF4066M1T AF N B IC(HCF4066) [IC4]
99 VHIW24257S7LL AP B IC(W24257S-70LLT) [IC5]
100 VHIHCF4053M1T AG N B IC(HCF4053B) [IC6]
101 VHIULN2003AN/ AE B IC(ULN2003ANS) [IC7]
102 QSOCZ2053XH32 AK C IC socket(32pin) [IC8]
VHI27010FWR0F BA B IC,EPROM(1MB) [IC8][108U]
VHI27010FWS0F BA B IC,EPROM(1MB) [IC8][178U/188U/375U]
105 VHILM2902D/-1 AH N B IC(LM2902D) [IC9]
106 VHINJM2904M-2 AG N B IC(NJM2904M) [IC10]
107 VHIPST596CMT1 AF B IC(PST596CNR) [IC100]
108 RCILZ2145XHZZ AF N C Coil(Z2145) [L102]
109 RCILZ2145XHZZ AF N C Coil(Z2145) [L103]
110 RCILZ2145XHZZ AF N C Coil(Z2145) [L104]
111 RCILZ2145XHZZ AF N C Coil(Z2145) [L105]
112 VHPITR9606/-1 AG N B Photo transistor(ITR9606) [PI1][178U/188U/375U]
113 VS2SD1858Q2-1 AE N B Transistor(2SD1858) [Q1][178U/188U/375U]
114 VS2SC2412KS-1 AB B Transistor(2SC2412-K) [Q101]
115 VS2SA1037KS-1 AB B Transistor(2SA1037KS) [Q102]
116 VSRNC1402//-1 AC B Transistor(RNC1402) [Q103][178U/188U/375U]
117 VRS-RE3AA270J AC N C Resistor(1W 27Ω ±5%) [R1][178U/188U/375U]
118 VRS-TS2AD221J AA C Resistor(1/10W 220Ω ±5%) [R100][178U/188U/375U]
119 VRS-TS2AD102J AA C Resistor(1/10W 1.0KΩ ±5%) [R101]
120 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R102]
121 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R103]
122 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R104]
123 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R105][178U/188U/375U]
124 VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R106][178U/188U/375U]
125 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R109]
126 VRS-TS2AD121J AA C Resistor(1/10W 120Ω ±5%) [R110]
127 VRS-TS2AD201J AG C Resistor(1/10W 200Ω ±5%) [R111]
128 VRSTS2AD4752F AA C Resistor(1/10W 47.5KΩ ±1%) [R112]
129 VRS-TS2AD271J AA C Resistor(1/10W 270Ω ±5%) [R113]
130 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R114]
131 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R115]
132 VRS-TS2AD224J AA C Resistor(1/10W 220KΩ ±5%) [R116]
133 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R119]
134 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R125]
135 VRS-TS2AD104J AA C Resistor(1/10W 100KΩ ±5%) [R126]
136 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R127]
137 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R128]
138 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R129]
139 VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R130]
140 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R131]
141 VRS-TS2AD3R0J AA C Resistor(1/10W 3Ω ±5%) [R136]
142 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R137][108U]
143 VRS-TS2AD473J AA C Resistor(1/10W 47KΩ ±5%) [R138]
144 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R139]
145 VRS-TS2AD104J AA C Resistor(1/10W 100KΩ ±5%) [R140]
146 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R141]
147 VRS-TS2AD224J AA C Resistor(1/10W 220KΩ ±5%) [R142]
148 VRS-TS2AD302J AA C Resistor(1/10W 3.0KΩ ±5%) [R143]
149 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R145]
150 VRS-TS2AD223J AA C Resistor(1/10W 22KΩ ±5%) [R146]
151 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R149]
152 VRS-TS2AD106J AA C Resistor(1/10W 10MΩ ±5%) [R155]
153 RCILZ2145XHZZ AF N C Coil(Z2145) [R156]
154 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R157]
155 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R158]
156 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R159]
157 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R162]
158 VRS-TS2AD203J AA C Resistor(1/10W 20KΩ ±5%) [R163]
159 VRS-TS2AD202J AA C Resistor(1/10W 2KΩ ±5%) [R164]
160 VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R165]
161 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R166]
