Sharp UX-178 Service Manual

UX-108U/178U/188U
FO-375U
NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
– 10 –
[7] Control PWB unit
162 VRS-TS2AD271J AA C Resistor(1/10W 270Ω ±5%) [R168]
163 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R169]
164 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R170]
165 RCILZ2139SCZZ AC C Coil(Z2139) [R171]
166 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R172]
167 RCILZ2145XHZZ AF N C Coil(Z2145) [R174]
168 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R175]
169 VRS-TS2AD302J AA C Resistor(1/10W 3.0KΩ ±5%) [R176]
170 VRS-TS2AD623J AA C Resistor(1/10W 62KΩ ±5%) [R177]
171 VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R178]
172 VRS-TS2AD102J AA C Resistor(1/10W 1.0KΩ ±5%) [R179]
173 VRS-TS2AD102J AA C Resistor(1/10W 1.0KΩ ±5%) [R181]
174 VRS-TS2AD102J AA C Resistor(1/10W 1.0KΩ ±5%) [R183]
175 VRS-TS2AD271J AA C Resistor(1/10W 270Ω ±5%) [R184]
176 VRS-TS2AD271J AA C Resistor(1/10W 270Ω ±5%) [R185]
177 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R186]
178 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R187]
179 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R188][108U]
VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R188][178U/188U/375U]
181 VRS-TS2AD152J AA C Resistor(1/10W 1.5KΩ ±5%) [R189]
182 VRS-TS2AD512J AA C Resistor(1/10W 5.1KΩ ±5%) [R190]
183 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R191]
184 VRSTS2AD8662F AA C Resistor(1/10W 86.6KΩ ±1%) [R192]
185 VRS-TS2AD203J AA C Resistor(1/10W 20KΩ ±5%) [R193]
186 VRSTS2AD1742F AA C Resistor(1/10W 17.4KΩ ±1%) [R194]
187 VRSTS2AD8662F AA C Resistor(1/10W 86.6KΩ ±1%) [R195]
188 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R196][178U/188U/375U]
189 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R200]
190 VRS-TS2AD203J AA C Resistor(1/10W 20KΩ ±5%) [R201]
191 VRS-TS2AD474J AA C Resistor(1/10W 470KΩ ±5%) [R202]
192 VRS-TS2AD223J AA C Resistor(1/10W 22KΩ ±5%) [R204]
193 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R205]
194 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R206]
195 VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R207]
196 VRS-TS2AD333J AA C Resistor(1/10W 33KΩ ±5%) [R209][178U/188U/375U]
197 VRS-TS2AD201J AG C Resistor(1/10W 200Ω ±5%) [R210][178U/188U/375U]
198 VRS-TS2AD333J AA C Resistor(1/10W 33KΩ ±5%) [R211]
199 VRS-TS2AD562J AA C Resistor(1/10W 5.6KΩ ±5%) [R212]
200 VRS-TS2AD333J AA C Resistor(1/10W 33KΩ ±5%) [R213]
201 VRS-TS2AD271J AA C Resistor(1/10W 270Ω ±5%) [R214]
202 VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R215]
203 VRS-TS2AD302J AA C Resistor(1/10W 3.0KΩ ±5%) [R216]
204 VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R217][178U/188U/375U]
205 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R218]
206 VRS-TS2AD152J AA C Resistor(1/10W 1.5KΩ ±5%) [R219]
207 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R220]
208 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R221]
209 VRS-TS2AD473J AA C Resistor(1/10W 47KΩ ±5%) [R222]
210 VRS-TS2AD473J AA C Resistor(1/10W 47KΩ ±5%) [R223]
211 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R224]
212 VRS-TS2AD133J AA C Resistor(1/10W 13KΩ ±5%) [R225]
213 VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R226]
214 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R227][178U/188U/375U]
215 VRS-TS2AD562J AA C Resistor(1/10W 5.6KΩ ±5%) [R228]
216 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R229]
217 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R230]
218 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R231]
219 VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R232]
220 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R233]
221 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R234]
222 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R235][108U]
VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [R235][178U/188U/375U]
224 VRS-TS2AD201J AG C Resistor(1/10W 200Ω ±5%) [R236]
225 VRS-TS2AD271J AA C Resistor(1/10W 270Ω ±5%) [R237]
226 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R238][178U/188U/375U]
227 VRS-TS2AD121J AA C Resistor(1/10W 120Ω ±5%) [R239]
228 RMPTY8103SCJF AF C Block resistor(1/8W 10KΩ ±1%) [RA1]
229 RMPTW4271SCJF AD C Block resistor(1/8W 270Ω ±1%) [RA2]
230 RMPTW4271SCJF AD C Block resistor(1/8W 270Ω ±1%) [RA3]
231 RMPTW4271SCJF AD C Block resistor(1/8W 270Ω ±1%) [RA4]
232 RMPTW4271SCJF AD C Block resistor(1/8W 270Ω ±1%) [RA5]
233 RMPTW4271SCJF AD C Block resistor(1/8W 270Ω ±1%) [RA6]
234 RMPTW4471SCJF AD C Block resistor(1/8W 470Ω ±1%) [RA7]
235 QSW-M2259XHZZ AF N B Door sensor [SW1]
236 RCRSB2122SCZZ AH N B Crystal(24.00014MHz) [X1]
237 RCRSB0297AFZZ AD B Crystal(32.768KHz) [X2]
238 TLABP3078SCZZ AA D Shading label(for EP-ROM)
(Unit)
901 DCEKC587JXHZZ BV N E Control PWB unit(Within ROM) [108U]
DCEKC586JXHZZ BZ N E Control PWB unit(Within ROM) [178U/188U/375U]
