Sharp UX-178 Service Manual

UX-108U/178U/188U
FO-375U
NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
– 11 –
[8] TEL/Liu PWB unit
1 VHVRA391PV6-1 AE B Varistor(RA391PV6) [AR1]
2 QCNW-4753XHZZ AE N C Cable [ARG]
3 VCKYPU1HB222K AA C Capacitor(50WV 2200PF) [C1]
4 RC-FZ3024SCZZ AG C Capacitor(250WV 0.82µF) [C2]
5 VCKYPU1HB222K AA C Capacitor(50WV 2200PF) [C3]
6 VCKYPU1HB222K AA C Capacitor(50WV 2200PF) [C4]
7 VCKYPU1HB103K AA C Capacitor(50WV 0.010µF) [C5]
8 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C6]
9 VCEAGA1HW475M AA C Capacitor(50WV 4.7µF) [C7]
10 VCQYNA1HM333K AA C Capacitor(50WV 0.033µF) [C8]
11 VCKYPU1HB102K AA C Capacitor(50WV 1000PF) [C9]
12 VCKYPU1HB102K AA C Capacitor(50WV 1000PF) [C10]
13 VCEAGA1HW475M AA C Capacitor(50WV 4.7µF) [C11]
14 VCEAGA1HW475M AA C Capacitor(50WV 4.7µF) [C12]
15 VCEAGA1HW225M AA C Capacitor(50WV 2.2µF) [C13]
16 VCEAGA1HW475M AA C Capacitor(50WV 4.7µF) [C14]
17 VCKYPU1HB102K AA C Capacitor(50WV 1000PF) [C15]
18 VCKYPU1HB102K AA C Capacitor(50WV 1000PF) [C16]
19 VCKYPU1HB221K AB C Capacitor(50WV 220PF) [C17]
20 VCKYPU1HB332K AA C Capacitor(50WV 3300PF) [C18]
21 VCKYPU1HF223Z AA C Capacitor(50WV 0.022µF) [C19]
22 RRLYD3221SCZZ AN B Relay [CML]
23 QCNCM2548SC1B AH N C Connector(12pin) [CNLIU]
24 VHDDSS133//-1 AA B Diode(1SS133) [D1]
25 VHDDSS133//-1 AA B Diode(1SS133) [D2]
26 VHDDSS133//-1 AA B Diode(1SS133) [D3]
27 VHDDSS133//-1 AA B Diode(1SS133) [D4]
28 VHINJM2904D-1 AG B IC(NJM2904D) [IC1]
29 RFILN2024XHZZ AG C Coil(N2024) [L7]
30 QJAKZ2069SCBB AG N C Jack [MJ1/2]
31 QJAKZ2070SC0D AF N C Jack [MJTEL]
32 VHPPC814X//-1 AE B Photo transistor(PC814X) [PC1]
33 VHPTLP521-1BL AE B Photo coupler(TLP521) [PC2]
34 VSDTC114ES/-1 AB B Transistor(DTC114ES) [Q1]
35 VS2SC1815GR-1 AB B Transistor(2SC1815GR) [Q2]
36 VSDTC114ES/-1 AB B Transistor(DTC114ES) [Q3]
37 VRD-HT2EY151J AA C Resistor(1/4W 150Ω ±5%) [R2]
38 VRD-HT2EY300J AA C Resistor(1/4W 30Ω ±5%) [R3]
39 VRD-HT2EY910J AA C Resistor(1/4W 91Ω ±5%) [R4]
40 VRD-HT2HY223J AA C Resistor(1/2W 22KΩ ±5%) [R5]
41 VRD-HT2EY223J AA C Resistor(1/4W 22KΩ ±5%) [R6]
42 VRD-HT2EY103J AA C Resistor(1/4W 10KΩ ±5%) [R9]
43 VRD-HT2EY103J AA C Resistor(1/4W 10KΩ ±5%) [R10]
44 VRD-HT2EY152J AA C Resistor(1/4W 1.5KΩ ±5%) [R11]
45 VRD-HT2EY102J AA C Resistor(1/4W 1.0KΩ ±5%) [R12]
46 VRD-HT2EY152J AA C Resistor(1/4W 1.5KΩ ±5%) [R13]
47 VRD-HT2EY153J AA C Resistor(1/4W 15KΩ ±5%) [R14]
48 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ±5%) [R15]
49 VRD-HT2EY103J AA C Resistor(1/4W 10KΩ ±5%) [R16]
50 VRD-HT2EY103J AA C Resistor(1/4W 10KΩ ±5%) [R17]
51 VRD-HT2EY102J AA C Resistor(1/4W 1.0KΩ ±5%) [R18]
52 VRD-HT2EY103J AA C Resistor(1/4W 10KΩ ±5%) [R19]
53 VRD-HT2EY153J AA C Resistor(1/4W 15KΩ ±5%) [R20]
54 VRD-HT2EY621J AA C Resistor(1/4W 620Ω ±5%) [R21]
55 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ±5%) [R22]
56 VRD-HT2EY102J AA C Resistor(1/4W 1.0KΩ ±5%) [R23]
57 QSW-Z2263XHZZ AG N B Hook switch [SW1]
58 RTRNZ2128XH01 AP B Transformer(Z2128) [T1]
59 VHVERZV5D471/ AC B Varistor(ERZVA5D471) [VA1]
60 VHVERZV5D471/ AC B Varistor(ERZVA5D471) [VA2]
61 VHEHZ2C1///-1 AA B Zener diode(HZ2C1-TA) [ZD1]
62 VHEHZ2C1///-1 AA B Zener diode(HZ2C1-TA) [ZD2]
63 VHEHZ27-1//-1 AB B Zener diode(HZ27C-1TA) [ZD3]
64 VHEHZ2C1///-1 AA B Zener diode(HZ2C1-TA) [ZD4]
65 VHEHZ2C1///-1 AA B Zener diode(HZ2C1-TA) [ZD5]
(Unit)
901 DCEKL366BXH01 BE N E TEL/Liu PWB unit
[9] Power supply PWB unit
1 0CBUGZ1063ZZ/ AF N C Capacitor(CFJC22E104M-X) [C1]
2 0CBUGZ1060ZZ/ AL C Capacitor(KMF200VB-220M 18x30) [C5]
3 0CBUGFQ103DU/ AF N C Capacitor(ECQE4103KF) [C6]
4 0CBUGCU102CB/ AD N C Capacitor(ECKZ3A102KBP) [C7]
5 0CBUGFF103AR/ AC C Capacitor(AMZ-103K50) [C8]
6 0CBUGFF683AR/ AD C Capacitor(AMZ-683K50) [C9]
7 0CBUGFF102AR/ AB C Capacitor(AMZ-102K50) [C10]
