Sharp UX-178 Service Manual

UX-108U/178U/188U
FO-375U
NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
– 12 –
[9] Power supply PWB unit
8 0CBUGFF102AR/ AB C Capacitor(AMZ-102K50) [C11]
9 0CBUGCZ472HN/ AF N C Capacitor(ECKMRS472MEY) [C12]
10 0CBUGCZ332HN/ AE N C Capacitor(ECKMRS332MEY) [C13]
11 0CBUGFF102AR/ AB C Capacitor(AMZ-102K50) [C14]
12 0CBUGAE681UG/ AH C Capacitor(UPJ1V681MHH1AA) [C15]
13 0CBUGCZ222AD/ AC C Capacitor(DD08E222P500V) [C16]
14 0CBUGAC471UM/ AF C Capacitor(UPJ1C471MPH6AA) [C18]
15 0CBUGAF1R0HD/ AC C Capacitor(UVZ1H010MDH1AA) [C19]
16 0CBPKZ0194ZZ/ AC C Connector(B 2P3-VH) [CN1]
17 0CBPKZ1105ZZ/ AH N C Connector(10PL-FJ) [CN2]
18 0CBUBC0215CZ/ AD N B Diode(RL1N4004) [D1]
19 0CBUBC0215CZ/ AD N B Diode(RL1N4004) [D2]
20 0CBUBC0215CZ/ AD N B Diode(RL1N4004) [D3]
21 0CBUBC0215CZ/ AD N B Diode(RL1N4004) [D4]
22 0CBUBC0169CZ/ AF N B Diode(ERA22-06) [D5]
23 0CBUBA0003BZ/ AD N B Diode(IS2076A) [D6]
24 0CBUBC0336AZ/ AL N B Diode(S3L20U-4004P15) [D7]
25 0CBUBC0302AZ/ AE B Diode(SR140) [D8]
26 0CBUBA0003BZ/ AD N B Diode(IS2076A) [D9]
27 0CBPJCSX2501/ AH A Current fuse(23702.5 ME600) [F1]
28 0CBPZZ0906ZZ/ AH N A Circuit protect chip(CCP2E100) [F3]
29 0CBBFZ89209Z/ AC C Ferrite core(BL01RN1-A62) [FB1]
30 0CBUCB0196AZ/ AR N B IC(BA178M05T) [IC1]
31 0CBUKZ0776ZZ/ AK C Filter(ELF15N007A) [L1]
32 0CBUDC0062AZ/ AF B Photo coupler(PS2501-1) [PC1]
33 0CBUAG0166BZ/ AQ N B FET(FS10KM-10) [Q1]
34 0CBUAC0027CZ/ AG B Transistor(2SC2655-Y) [Q2]
35 0CBUAC0034EZ/ AE B Transistor(2SC1740S) [Q3]
36 0CBUAC0264AZ/ AD N B Transistor(2SC1741AS QR) [Q4]
37 0CBUEEB564CS/ AC N C Resistor(RD16S 564J) [R1]
38 0CBUEFER18CH/ AD C Resistor(SPRX2-R18J) [R2]
39 0CBUEEB822CS/ AC N C Resistor(RD16S 822J) [R3]
40 0CBUEEB101CS/ AC N C Resistor(RD16S 101J) [R4]
41 0CBUEEB184CS/ AC N C Resistor(RD16S 184J) [R5]
42 0CBUEEB154CS/ AC N C Resistor(RD16S 154J) [R6]
43 0CBUEFE823CG/ AC C Resistor(RSS2 823J) [R7]
44 0CBUEEB681CB/ AC N C Resistor(RD50SS 681J) [R8]
45 0CBUEEB681CS/ AC N C Resistor(RD16S 681J) [R9]
46 0CBUEEB220CS/ AC N C Resistor(RD16S 220J) [R10]
47 0CBUEEB681CS/ AC N C Resistor(RD16S 681J) [R11]
48 0CBUEEB222CS/ AC N C Resistor(RD16S 222J) [R12]
49 0CBUEEB271CS/ AC N C Resistor(RD16S 271J) [R13]
50 0CBUEEB392CS/ AC N C Resistor(RD16S 392J) [R14]
51 0CBUEEB122CS/ AC N C Resistor(RD16S 122J) [R15]
52 0CBUEEB681CB/ AC N C Resistor(RD50SS 681J) [R16]
53 0CBPHZ0184ZZ/ AR N B Relay(AJS3312) [RY1]
54 0CB829655007/ BE B Transformer(PT-U53-KTT) [T1]
55 0CBUDC0232ZZ/ AF N B Thermistor(KL07L8R2F) [TH1]
56 0CBUEZ0528ZZ/ AD N B Varistor(ERZV07D241-CS) [V1]
57 0CBUFBA471CB/ AD N B Variable resistor(EVN DJA A03 BQ2(471)) [VR1]
58 0CBUBDAC3R9C/ AD B Zener diode(RD3.9ESAB2) [ZD2]
59 0CBUBDAC6R2C/ AC B Zener diode(RD6.2ESAB2) [ZD3]
60 0CBUBDAE300D/ AD B Zener diode(RD30FB3) [ZD4]
61 0CBLRZ6446ZP/ AQ N C Heat sink(J7E36-5001AT)
62 0CBLRZ6447ZP/ AQ N C Heat sink(J7E36-5002AT)
(Unit)
!
901 RDENT2116XHZZ BN N E Power supply PWB unit
[50] Hardware parts
B1 XBBSD30P06000 AA C Screw(3x6)
B2 LX-BZ2138XHZZ AB C Screw
B3 XUBSD20P06000 AA C Screw(2x6)
B4 XEBSD30P10000 AA C Screw(3x10)
B5 LX-BZ2222AXZZ AC C Screw
B6 XEBSD30P12000 AA C Screw(3x12)
B7 XBPSN40P06K00 AA C Screw(4x6)
