SHE EM - Kippfenster Flügelmontage

10 02/13424999459
RWA Kettenantrieb EM/S/MKAZ/UL
7.2 Kippfenster Flügelmontage
V2
Montage am Kippfenster (Flügelmontage)
40
40
40
In
Out
A
B
C
1
Z
Y/1 Y/2
1
2
4
3
2
1
2
3
4
4
5
6
C
B
6
5
4
3
6
5
1
3
15
20
40
34,5
16
15
18,5
15
10
16
18,5
SBEM-KF0
SBEM-KF10 SBEM-KF15
X = 327 mm Hub: A = 561 mm
X = 419 mm Hub: A = 653 mm
X = 511, 603 mm Hub: A = 837 mm
X = 810 mm Hub: A = 1028 mm
B > 38 mm C = 0 mm (SBEM-KF0)
C = 10 mm (SBEM-KF10)
C = 15 mm (SBEM-KF15)
X = 327 mm Hub:
Y/1 = Y/2 = 265,5 mm
Z = 531 mm
X = 419 mm Hub:
Y/1 = Y/2 = 311,5 mm
Z = 623 mm
X = 511, 603 mm Hub:
Y/1 = Y/2 = 403,5 mm
Z = 807 mm
X = 810 mm Hub:
Y/1 = Y/2 = 499 mm
Z = 998 mm
