SHE EM - Tilt Window Frame Mounting

22 02/13424999459
SHE chain drive EM/S/MKAZ/UL
7.3 Tilt window Frame mounting
V3
Montage am Kippfenster (Rahmenmontage)
1
2
Z
Y/1
Y/2
B
C
B
A
C
4
4.1
3
2
1
4.1
1
2
3
6
4
3
5
6
5
4
3
6
5
4
3
B = 1,81 inch C = 0 inch (SBEM-R0)
C = 0.39 inch (SBEM-R10)
C = 0.59 inch (SBEM-R15)
0.39 inch 0.59 inch
0.59 inch
1.18 inch
0.59 inch
0.59 inch
0.59 inch
0.47 inch
0.47 inch
0.59 inch
0.75 inch
0.75 inch
SBEM-R0 SBEM-R10 SBEM-R15
X = 12.87 inch stroke: A = 23.31 inch
X = 16.5 inch stroke: A = 26.97 inch
X = 20.12, 23.74 inch stroke: A = 34.17 inch
X = 31.89 inch stroke: A = 41.73 inch
X = 12.87 inch stroke:
Y/1 = Y/2 = 11.16 inch
Z = 22.32 inch
X = 16.5 inch stroke:
Y/1 = Y/2 = 12.97 inch
Z = 25.94 inch
X = 20.12, 23.74 inch stroke:
Y/1 = Y/2 = 16.59 inch
Z = 33.19 inch
X = 31.89 inch stroke:
Y/1 = Y/2 = 20.37 inch
Z = 40.75 inch
