SHE EM - Dachfenstermontage

9
02/13424999459
Montage am Dachfenster
A
B
C
A/2
A/2
X= 21-511mm: A min. = 868mm
X= 21-603mm: A min. = 1060mm
X= 21-810mm: A min. = 1060mm
B = 40mm
C = 23mm
1
k
k
Z
Y/2
Y/1
k
Z
4
4
3
2
2
4
4
3
1
1
2
6
5
4
3
6
5
V1
1
3
RWA Kettenantrieb EM/S/MKAZ/UL
7.1 Dachfenstermontage
15
18
23
X = 327 mm Hub
A = 592 mm
X = 419 mm Hub
A = 685 mm
X = 511, 603 mm Hub
A = 868 mm
X = 810 mm Hub
A = 1060 mm
B = 40 mm C = 23 mm
X = 327 mm Hub
Y/1 = Y/2 = 283,5 mm
Z = 567 mm
X = 419 mm Hub
Y/1 = Y/2 = 329,5 mm
Z = 659 mm
X = 511, 603 mm Hub
Y/1 = Y/2 = 421,5 mm
Z = 843 mm
X = 810 mm Hub
Y/1 = Y/2 = 517,5 mm
Z = 1035 mm
20
28
23
18
20
